The BMW R 1200RT is a game-changer for long-distance touring, boasting a dramatically styled new bodywork that sets it apart from its predecessor. The innovative design not only provides improved rider and passenger comfort but also integrates rearview mirrors and turn-signals to manage airflow and reduce turbulence.
At the heart of this motorcycle is a powerful and refined engine, delivering the perfect balance of power and character. The R 1200RT’s large engine-oil cooler is cleverly concealed behind a prominent split grill, while the geometrically optimized headlight provides superior nighttime illumination.
The riding experience is nothing short of exceptional, with an ergonomic profile that’s both familiar and new. The ideal seat-handlebar-footpeg relationship places the rider in a comfortable, upright position, reducing fatigue and improving control. With seating options aplenty, including a split saddle and adjustable rider’s seat, the R 1200RT is the ultimate touring companion for riders of all shapes and sizes. Whether you’re embarking on a weekend getaway or a month-long odyssey, the BMW R 1200RT is the perfect machine for the journey.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Capacity
1170 cc / 71.4 cu in
Max Power
81 kw / 110 hp
Max Torque
115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm
Fuel Tank Capacity
27 Liters / 7.1 US gal
Weight (Wet/Kerb)
570.9 lbs / 259 kg
Seat Height
32.2 inches / 820 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1200RT
Year
2006
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
System Enclosed driveshaft with two universal joints
Electrical & Electronics System
Battery
12 V / 14 Ah, maintenance-free
Starter
Electric
Chassis & Suspension
Frame Type
Three-section frame consisting of front and rear section, load bearing engine-gearbox unit
Front Suspension
BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA
Rear Suspension Travel
5.3 inches / 135 mm
Trail
63.8
Wheels & Brakes
Wheels
Cast aluminium
Front Wheel/Rim Size
3.50 x 17
Front Tire Size
120/70 ZR17
Rear Wheel/Rim Size
5.50 x 17
Rear Tire Size
180/60 ZR17
Front Brakes
2 x 320mm Discs, 4 piston callipers
Rear Brakes
Single 265mm disc, 2 piston caliper
Dimension & Weights
Seat Height
32.2 inches / 820 mm
Wheelbase
58.4 inches / 1485 mm
Ground Clearance
155 mm / 6.1 in
Fuel Tank Capacity
27 Liters / 7.1 US gal
Wet (kerb/curb) Weight
570.9 lbs / 259 kg
Dry Weight
229 kg / 485.0 lbs
Features
Dramatically styled new bodywork
Improved rider and passenger comfort
Integrated rearview mirrors/turn-signals
Improved aerodynamics
Taller and wider windscreen
Better rider protection and passenger weather protection
Prominent split grill for engine-oil cooling
“Freeform” headlight
Geometrically optimized surface contours for nighttime illumination
H7 halogen bulbs for low beam and high beam
Ergonomic profile based on R 1150 RT
Ideal seat-handlebar-footpeg relationship for long-range touring
Split saddle with two-position adjustment
Lower seat available for reduced overall seat height
Resculpted seats and legroom for surefooted handling
Dynamic new bodywork for effective air flow
Electrically adjustable windshield
Rail mounting system for optional tank bag
32-liter hard saddlebags with four-point mounting system and weather-resistant seals
Locks keyed to the ignition key
Integrated luggage rack for extra gear or optional topcases
