The BMW R 1200RS LC is a masterclass in sports touring, distilling the essence of speed, comfort, and agility into a single, exhilarating package. Its 1170cc flat-twin engine, a variant of the GS’s potent powerplant, delivers a thrilling 125bhp and 92ft-lb of torque, with an unmistakable boxer growl that’s music to the ears.
The RS’s sporty handling and stiffer suspension are perfectly complemented by its ergonomic riding position, allowing riders to carve through twisties with confidence and precision. A steering damper ensures stability on uneven terrain, while a 62.3-degree head angle and 1530mm wheelbase provide exceptional stability at high speeds.
The legendary RS badge, revived after a decade-long hiatus, is a badge of honor for those who crave the perfect blend of performance and comfort. With its 18-liter tank and 236kg curb weight, the R 1200RS LC is an ideal companion for both short blasts and long-distance touring, making it the ultimate sports touring machine that truly takes the genre to new and thrilling heights.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder,Intake 40mm outlet 34 mm
Engine Capacity
1170 cc / 71.4 cub in.
Max Power
92 kw / 125 hp
Max Torque
125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm
Fuel Tank Capacity
5.3 US gallons / 18.0 L
Weight (Wet/Kerb)
509.2 lbs / 231 kg
Seat Height
29.9 inches / 760 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1200RS LC
Year
2016
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder,Intake 40mm outlet 34 mm
Displacement
1170 cc / 71.4 cub in.
Bore x Stroke
101 x 73 mm
Compression Ratio
12.5:1
Max Horsepower
92 kw / 125 hp
Max Torque
125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm
Engine Management System
Throttle valve mm 52Carburetion BMS-XEmission control Closed-loop 3-way catalytic converter
Cooling System
Liquid / Air cooled
Fuel
Premium unleaded (95 RON)
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Oil lubricated clutch, hydraulically operated
Gearbox
Constant mesh 6-speed gearbox with helical gear teeth
Final Drive
Shaft
Electrical & Electronics System
Battery
12 V / 11,8 Ah, maintenance-free
Starter
Electric
ABS
BMW Motorrad Integral ABS (part-integral), disengageable
Chassis & Suspension
Frame Type
Two-section frame, front- and bolted on rear frame, load-bearing engine
Front Suspension
Telescopic Upside-Down fork; stanchion diameter 45 mm
Front Suspension Travel
5.5 inches / 140 mm
Rear Suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Rear Suspension Travel
5.5 inches / 140 mm
Trail
62,3
Wheels & Brakes
Front Wheel/Rim Size
3.50 x 17″
Front Tire Size
120/70 ZR 17
Rear Wheel/Rim Size
5.50 x 17″
Rear Tire Size
180/55 ZR 17
Front Brakes
2 X 320 floating discs 4 piston calipers
Rear Brakes
Single 275mm disc 2 piston caliper,
ABS
BMW Motorrad Integral ABS (part-integral), disengageable
Dimension & Weights
Seat Height
29.9 inches / 760 mm
Wheelbase
60.1 inches / 1527 mm
Fuel Tank Capacity
5.3 US gallons / 18.0 L
Wet (kerb/curb) Weight
509.2 lbs / 231 kg
Max Load Capacity
450 kg / 992 lbs
Features
Four stroke, two cylinder horizontally opposed Boxer engine
DOHC, 4 valves per cylinder
Semi-liquid-cooled 1170cc flat-twin engine
Constant mesh 6-speed gearbox with helical gear teeth
Electronically Adjustable Suspension (ESA)
Traction control
ABS
Riding modes (Road, Rain, and dynamic setting)
Gear assist system for clutchless upshifts and downshifts
Forged aluminium handlebar unit
Symmetrical headlamps
Dual headlights
Sporty riding position
Stiffer suspension
Steeper steering geometry
Steering damper
Long-travel suspension for improved comfort
Low-down torque
92ft-lb of torque
125bhp
18-litre fuel tank
