The BMW R 1200 R LC embodies the perfect blend of style, performance, and comfort. Its horizontally opposed Boxer engine produces a potent 125 horsepower, thanks in part to the DOHC, 4-valve design and fuel injection system.
Its 6-speed constant mesh gearbox features helical gear teeth for smooth, precise shifting, while the upside-down telescopic fork provides exceptional stability and handling, inspired by the S 1000 RR.
The R 1200 R’s design is a striking fusion of muscle and elegance, with a compact, athletic silhouette and sharply drawn lines that perfectly capture its dynamic personality.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder,intake 40mm, outlet 34 mm
Engine Capacity
1170 cc / 71.4 cub in.
Max Power
92 kw / 125 hp
Max Torque
125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm
Fuel Tank Capacity
18 Liters / 5.3 US gal
Weight (Wet/Kerb)
509.2 lbs / 231 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1200R LC
Year
2017
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder,intake 40mm, outlet 34 mm
Displacement
1170 cc / 71.4 cub in.
Bore x Stroke
101 x 73 mm
Compression Ratio
12.5:1
Max Horsepower
92 kw / 125 hp
Max Torque
125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm
Engine Management System
Throttle valve mm 52Carburetion BMS-XEmission control Closed-loop 3-way catalytic converter
Cooling System
Liquid / Air cooled
Fuel
Premium unleaded (95 RON)
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Oil lubricated clutch, hydraulically operated
Gearbox
Constant mesh 6-speed gearbox with helical gear teeth
Final Drive
Shaft
Electrical & Electronics System
Battery
12 V / 11,8 Ah, maintenance-free
Starter
Electric
ABS
BMW Motorrad Integral ABS (part-integral), disengageable
Chassis & Suspension
Frame Type
Two-section frame, front- and bolted on rear frame, load-bearing engine
Front Suspension
Telescopic Upside-Down fork; stanchion diameter 45 mm
Front Suspension Travel
5.5 inches / 140 mm
Rear Suspension Travel
5.5 inches / 140 mm
Trail
62.3
Wheels & Brakes
Front Wheel/Rim Size
3.50 x 17
Front Tire Size
120/70 ZR 17
Rear Wheel/Rim Size
5.50 x 17
Rear Tire Size
180/55 ZR 17
Front Brakes
2 x 320 floating discs, 4 piston calipers
Rear Brakes
Single 275mm disc, 2 piston caliper
ABS
BMW Motorrad Integral ABS (part-integral), disengageable
Dimension & Weights
Wheelbase
59.6 inches / 1515 mm
Fuel Tank Capacity
18 Liters / 5.3 US gal
Wet (kerb/curb) Weight
509.2 lbs / 231 kg
Max Load Capacity
450 kg / 992 lbs
Features
Four stroke, two cylinder horizontally opposed Boxer
DOHC, 4 valves per cylinder
Intake 40mm, outlet 34 mm
Constant mesh 6-speed gearbox with helical gear teeth
Upward telescopic fork
Dynamic ESA (optional)
Traction control (DTC) (optional)
Riding modes (accessed at press of a button)
Redesigned and expanded instrument panel
Aluminum bridge in cockpit
Tank rucksack
BMW Navigator V
Four different windshields
Shift Assistant Pro (optional)
Keyless Ride (optional)
Milled hand lever
Rider footrests
Crash bar in electropolished stainless steel
ABS Pro (optional)
Dynamic Brake Light (optional)
