BMW R 1200R (2011)

The BMW R 1200 R and R 1200 R Classic are the latest additions to BMW Motorrad’s roadster lineup, boasting a rich heritage and a commitment to innovation.

The heart of these dynamic machines is the revised boxer engine, a four-stroke, two-cylinder unit with DOHC and 4 valves per cylinder, generating perceptibly higher torques for a thrilling riding experience. With its roots in the successful R 1200 R, these new roadsters deliver even more riding fun, thanks to their modern sporty design and accentuated classical lines.

The boxer engine, borrowed from the HP2 Sport, is a game-changer, providing an extra boost of temperament to the riding experience. Paired with ultra-modern technology and two distinct design concepts, the BMW R 1200 R and R 1200 R Classic set a new standard in the segment, offering a unique blend of performance, style, and refinement.

Key Specifications

Engine Type	Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder
Engine Capacity	1170 cc / 71.4 cu in
Max Power	81 kw / 110 hp
Max Torque	120 Nm / 12.2 kgf-m / 88 lb-ft @ 6000 rpm
Fuel Tank Capacity	18 Litres / 4.7 gal
Weight (Wet/Kerb)	492 lbs / 223 kg
Seat Height	800mm / 31.5″ (Standard, OE, OA, sport seat) 830mm / 32.7″ (OE, OA, comfort seat, high) / 760mm / 29.9″ (OE, OA, seat, low) / 750mm / 29.5″ (OE, low slung)

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	BMW R 1200R
Year	2011

Engine

Engine Type	Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder
Displacement	1170 cc / 71.4 cu in
Bore x Stroke	101 x 73 mm
Compression Ratio	12.0:1
Max Horsepower	81 kw / 110 hp
Max Torque	120 Nm / 12.2 kgf-m / 88 lb-ft @ 6000 rpm
Engine Management System	Electronic intake manifold injection BMS-K
Cooling System	Air/Oil-cooled

Performance

Top Speed

220 km/h / 137 mph

*n/a – information not provided by manufacturer

Transmission

Clutch	Single disc dry clutch, hydraulically actuated
Gearbox	6 Speed
Gear Ratios	1st 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 0.065 / 5th 0.939 / 6th 0.848
Final Drive	Shaft

Electrical & Electronics System

Battery	12 V / 14 Ah, maintenance-free
Starter	Electric

Chassis & Suspension

Frame Type	Tubular steel spaceframe, load-bearing engine
Front Suspension	BMW Motorrad Telelever; stanchion diameter 41 mm, central spring strut
Front Suspension Travel	4.7 inches / 120 mm
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Rear Suspension Travel	5.5 inches / 140 mm
Trail	62.9

Wheels & Brakes

Wheels	Cast aluminium wheels
Front Tire Size	120/70-ZR 17
Rear Tire Size	180/55-ZR 17
Front Brakes	2 x 320mm Discs, ABS
Rear Brakes	Single 265mm disc, ABS

Dimension & Weights

Seat Height	800mm / 31.5″ (Standard, OE, OA, sport seat) 830mm / 32.7″ (OE, OA, comfort seat, high) / 760mm / 29.9″ (OE, OA, seat, low) / 750mm / 29.5″ (OE, low slung)
Wheelbase	59.1 inches / 1495 mm
Fuel Tank Capacity	18 Litres / 4.7 gal
Wet (kerb/curb) Weight	492 lbs / 223 kg
Dry Weight	198 kg / 436.5 lbs

Features

Four stroke, two cylinder horizontally opposed Boxer engine
DOHC, 4 valves per cylinder
1170 cc engine
Telelever suspension
Two part main/rear frame with steel tubing
Load-bearing engine design for maximum stiffness
High rigidity and strength
Cast light alloy wheels on R 1200 R
Wire spoke wheels on R 1200 R Classic
Metallic sapphire black paintwork on R 1200 R Classic
Centre stripe in plain alpine white on R 1200 R Classic
Nurburg silver wheels and drivetrain on R 1200 R
Mat metallic smoky grey, metallic light grey, or metallic red apple paintwork on R 1200 R
Brushed stainless steel rear silencer on R 1200 R
Black rearview mirrors on R 1200 R
Chromium-plated exhaust system on R 1200 R Classic
Chrome look mirrors on R 1200 R Classic
High torque engine
