BMW R 1200R (2009)

BMW R 1200R (2009)

The BMW R 1200R is a roadster that defies categorization, blending corner-carving agility with long-distance comfort and customization flexibility. Its 1200cc flat-twin engine unleashes a potent 109hp and 115Nm of torque, making it a thrilling companion on twisty roads and a capable tourer for extended journeys. Whether styled for sporty, classic, or touring duties, the R 1200R exudes timeless design and high-quality construction, backed by cutting-edge safety features and a suspension setup that effortlessly handles its 223kg weight. With a combination of performance, comfort, and versatility, the BMW R 1200R is an exceptional machine that leaves a lasting impression.

Key Specifications

Engine TypeFour stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Capacity1170 cc / 71.4 cu in
Max Power80 kw / 109 hp
Max Torque115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm
Fuel Tank Capacity4.7 US gallons / 18.0 L
Seat Height31.4 inches / 800 mm
BMW R 1200R (2009)

All Specifications

Make & Model

ModelBMW R 1200R
Year2009

Engine

Engine TypeFour stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Displacement1170 cc / 71.4 cu in
Bore x Stroke101 x 73 mm
Compression Ratio11.0:1
Max Horsepower80 kw / 109 hp
Max Torque115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm
Engine Management SystemElectronic intake manifold injection BMS-K
Cooling SystemAir/Oil-cooled

Performance

Top Speed219.6 km/h / 136 mph

Transmission

ClutchSingle disc dry clutch, hydraulically actuated
Gearbox6 Speed
Gear Ratios1st 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 0.065 / 5th 0.939 / 6th 0.848
Final DriveShaft

Electrical & Electronics System

Battery12 V / 14 Ah, maintenance-free
StarterElectric

Chassis & Suspension

Frame TypeTubular steel spaceframe, load-bearing engine
Front SuspensionBMW Motorrad Telelever; stanchion diameter 41 mm, central spring strut
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionCast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Rear Suspension Travel5.5 inches / 140 mm
Trail62.9

Wheels & Brakes

WheelsCast aluminium wheels
Front Tire Size120/70-ZR 17
Rear Tire Size180/55-ZR 17
Front Brakes2 x 320mm discs, ABS
Rear BrakesSingle 265mm disc, ABS

Dimension & Weights

Seat Height31.4 inches / 800 mm
Wheelbase59.1 inches / 1495 mm
Fuel Tank Capacity4.7 US gallons / 18.0 L
Dry Weight198 kg / 436.5 lbs

Features

  • 4-stroke, 2-cylinder horizontally opposed Boxer engine
  • 4 valves per cylinder
  • 1200 cc flat twin engine
  • 109 hp output
  • 115 Nm of torque
  • 223 kg fully fuelled weight
  • Telelever front suspension
  • Integral ABS
  • Automatic Stability Control (ASC)
  • Classic, sporty, and touring-oriented designs available
  • Wide range of accessories available
  • High-quality construction and design
  • Low center of gravity
  • Proven technology
  • Generous 109hp output
  • Latest version of BMW Integral ABS
  • Automatic Stability Control (ASC)
