The BMW R 1200GS LC Adventure Triple Black is a behemoth of a motorcycle, boasting a liquid-cooled Boxer engine that delivers a raw, unbridled power and character. The DOHC configuration and 4 valves per cylinder ensure a silky-smooth power delivery, while the 40mm intake and 34mm exhaust valves add to the engine’s muscular personality.
With its Triple Black special edition finish, this bike exudes a menacing, masculine presence on the road. The Blackstorm metallic tank, Dark Slate metallic side panels, and Agate Grey front and rear frame all contribute to a striking aesthetic that’s hard to ignore.
But it’s not just about looks – the BMW R 1200GS LC Adventure Triple Black is also a masterclass in engineering and innovation. With a raft of technical changes and updates, including a new judder damper, revised transmission components, and an OBD indicator lamp, this bike is a force to be reckoned with. Whether you’re tackling the open road or pushing the limits of off-road adventure, the BMW R 1200GS LC Adventure Triple Black is the ultimate travel enduro for those who refuse to compromise.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, intake 40mm, outlet 34 mm
Engine Capacity
1170 cc / 71.4 cub in.
Max Power
92 kw / 125 hp
Max Torque
125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm
Fuel Tank Capacity
7.9 US gallons / 30.0 L
Weight (Wet/Kerb)
573 lbs / 260 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1200GS LC Adventure Triple Black
Year
2017
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, intake 40mm, outlet 34 mm
Displacement
1170 cc / 71.4 cub in.
Bore x Stroke
101 x 73 mm
Compression Ratio
12.5:1
Max Horsepower
92 kw / 125 hp
Max Torque
125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm
Engine Management System
Throttle valve 52 mmCarburetion BMS-XEmission control Closed-loop 3-way catalytic converter
BMW Motorrad Telelever; diameter 37 mm, central spring strut
Front Suspension Travel
8.3 inches / 210 mm
Rear Suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring preload hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Rear Suspension Travel
8.7 inches / 220 mm
Trail
64.5
Wheels & Brakes
Front Wheel/Rim Size
3.00 x 19
Front Tire Size
120/70 R19
Rear Wheel/Rim Size
4.50 x 17
Rear Tire Size
170/60 R17
Front Brakes
2x 305mm Hydraulically actuated twin disc brake, BMW Motorrad Integral ABS (standard, part intergal, disengageable)
Rear Brakes
Single 275mm disc 2 piston caliper, BMW Motorrad Integral ABS (standard, part intergal, disengageable)
Dimension & Weights
Wheelbase
59.3 inches / 1507 mm
Fuel Tank Capacity
7.9 US gallons / 30.0 L
Wet (kerb/curb) Weight
573 lbs / 260 kg
Dry Weight
220 kg / 485 lbs
Features
2 cylinder, horizontally opposed Boxer engine
DOHC, 4 valves per cylinder
Intake 40mm, outlet 34 mm
Hydraulically actuated twin disc brake
BMW Motorrad Integral ABS (standard, part integral, disengageable)
Single 275mm disc 2 piston caliper
BMW Motorrad Integral ABS (standard, part integral, disengageable)
Blackstorm metallic central fuel tank cover
Blackstorm metallic storage compartment lid
Dark Slate metallic fuel tank side panels
Agate Grey front and rear frame
Black engine, gearbox, and swinging arm
Black seat with GS embossment
Liquid-cooled boxer engine
Judder damper on transmission output shaft
Revised selector drum actuator
Revised transmission shafts and transmission shaft bearing
OBD indicator lamp in the cockpit
