The 2016 BMW R 1200GS LC is a masterclass in motorcycle design and engineering, boasting a Four-stroke, two-cylinder horizontally opposed Boxer engine that delivers exceptional power and character.
With its DOHC configuration and 4 valves per cylinder, the R 1200GS LC is a marvel of efficiency, while the 52mm throttle valve and closed-loop 3-way catalytic converter ensure a smooth and refined ride.
On the road, the R 1200GS LC comes alive, its Telelever front suspension and Paralever rear suspension working in perfect harmony to provide a smooth and stable ride. And when the going gets tough, the bike’s impressive braking system, featuring 305mm twin disc brakes and BMW Motorrad Integral ABS, is more than up to the task.
Whether carving through twisties or cruising down the highway, the R 1200GS LC is a joy to ride, with its intuitive ergonomics and responsive handling making it an absolute blast to be on. And with its extensive range of special accessories, this bike can be tailored to suit any rider’s needs and preferences. The result is an unforgettable riding experience that will leave you grinning from ear to ear, and begging for more.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder,Intake 40mm, outlet 34 mm
Engine Capacity
1170 cc / 71.4 cub in
Max Power
92 kw / 125 hp
Max Torque
125 Nm /12.7 kgf-m / 92 lb-ft @ 6500 rpm
Fuel Tank Capacity
20 Liters / 5.3 US gal
Weight (Wet/Kerb)
525 lbs / 238 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1200GS LC
Year
2016
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder,Intake 40mm, outlet 34 mm
Construction type tubular steel bridge frame, engine self-supporting
Front Suspension
BMW Motorrad Telelever; stanchion 37 mm, central spring strut
Front Suspension Travel
7.5 inches / 190 mm
Rear Suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring preload hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Rear Suspension Travel
7.9 inches / 220 mm
Trail
64.5
Wheels & Brakes
Front Wheel/Rim Size
3.00 x 19
Front Tire Size
120/70 R19
Rear Wheel/Rim Size
4.50 x 17
Rear Tire Size
170/60 R 17
Front Brakes
2x 305mm Hydraulically actuated twin disc brake, BMW Motorrad Integral ABS (standard, part intergal, disengageable)
Rear Brakes
Single 275mm disc, 2 piston caliper, BMW Motorrad Integral ABS (standard, part intergal, disengageable)
Dimension & Weights
Wheelbase
59.3 inches / 1507 mm
Fuel Tank Capacity
20 Liters / 5.3 US gal
Wet (kerb/curb) Weight
525 lbs / 238 kg
Dry Weight
205 kg / 452 lbs
Features
Four stroke, two cylinder horizontally opposed Boxer engine
DOHC, 4 valves per cylinder
40mm intake throttle valve
34mm outlet throttle valve
52mm throttle body
Closed-loop 3-way catalytic converter
620W alternator
12V/12Ah maintenance-free battery
H7W headlight (LED headlight on SA model)
0.9kW starter
6-speed transmission
Tubular steel bridge frame
BMW Motorrad Telelever front suspension
Cast aluminum single-sided swing arm with BMW Motorrad Paralever rear suspension
WAD strut with continuously variable spring preload
305mm hydraulically actuated twin disc brake
BMW Motorrad Integral ABS (standard)
275mm single disc brake on rear wheel
Cast aluminum wheels and spokes or laced wire spokes
ABS Pro and dynamic brake light (optional)
