The BMW R 1200GS LC is a testament to the brand’s commitment to building motorcycles that embody the spirit of adventure and riding pleasure. At its heart lies a four-stroke, two-cylinder Boxer engine, boasting DOHC and 4 valves per cylinder for unparalleled power and efficiency.
The 52mm throttle valve and BMS-XE carburetion system work in harmony to deliver a smooth and responsive ride, while the closed-loop 3-way catalytic converter ensures minimal environmental impact. The bike’s tubular steel bridge frame and engine self-supporting BMW Motorrad Telelever provide a stable and agile platform for handling the most challenging terrain.
Whether carving through twisties or traversing rough terrain, the R 1200GS LC’s Cast aluminum single-sided swing arm and BMW Motorrad Paralever work in tandem with the Hydraulically actuated twin disc brake system to provide exceptional braking power and control. With its unique blend of power, comfort, and versatility, the BMW R 1200GS LC is poised to continue its legacy as one of the world’s greatest adventure motorcycles.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder,Intake 40mm, outlet 34 mm
Engine Capacity
1170 cc / 71.4 cub in
Max Power
92 kw / 125 hp
Max Torque
125 Nm /12.7 kgf-m / 92 lb-ft @ 6500 rpm
Fuel Tank Capacity
20 Liters / 5.3 US gal
Weight (Wet/Kerb)
525 lbs / 238 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1200GS LC
Year
2013
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder,Intake 40mm, outlet 34 mm
Construction type tubular steel bridge frame, engine self-supporting
Front Suspension
BMW Motorrad Telelever; stanchion 37 mm, central spring strut
Front Suspension Travel
7.5 inches / 190 mm
Rear Suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring preload hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Rear Suspension Travel
7.9 inches / 220 mm
Trail
64.5
Wheels & Brakes
Front Wheel/Rim Size
3.00 x 19
Front Tire Size
120/70 R19
Rear Wheel/Rim Size
4.50 x 17
Rear Tire Size
170/60 R 17
Front Brakes
2x 305mm Hydraulically actuated twin disc brake, BMW Motorrad Integral ABS (standard, part intergal, disengageable)
Rear Brakes
Single 275mm disc, 2 piston caliper, BMW Motorrad Integral ABS (standard, part intergal, disengageable)
Dimension & Weights
Wheelbase
59.3 inches / 1507 mm
Fuel Tank Capacity
20 Liters / 5.3 US gal
Wet (kerb/curb) Weight
525 lbs / 238 kg
Dry Weight
205 kg / 452 lbs
Features
Four stroke, two cylinder horizontally opposed Boxer engine
