The BMW R 1200GS Adventure is a behemoth of a motorcycle, boasting a four-stroke, two-cylinder horizontally opposed Boxer engine that delivers a potent mix of power and torque.
With electronic intake pipe injection and digital engine management, this engine is a masterpiece of modern engineering, providing seamless throttle response and effortless acceleration.
The Telelever suspension system, with its central spring strut and 41mm stanchion, sets the standard for stability and control, while the Die-cast aluminium single-sided swinging arm provides the perfect balance of agility and comfort.
But what truly sets the R 1200GS Adventure apart is its unique blend of on-road touring and off-road capability, making it the perfect companion for any adventure that comes its way. And with its impressive array of standard features, including a 33-litre fuel tank, adjustable windshield, and robust protection hoops, this bike is ready to take on the toughest terrain with confidence and poise.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Capacity
1170 cc / 71.4 in.
Max Power
73 kw / 98 hp
Max Torque
115 Nm / 11.7 kgf-m / 84.8 ft-lbs @ 5500 rpm
Fuel Tank Capacity
8.7 US gallons / 33.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1200GS Adventure
Year
2006
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Telelever, stanchion ∅41mm, central spring strut, spring preload 9 times mechanically adjustable.
Front Suspension Travel
8.3 inches / 210 mm
Rear Suspension
Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever, WAD strut (travel-related damping), spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, rebound damping adjustable.
Rear Suspension Travel
8.7 inches / 220 mm
Trail
101 mm / 4.0 in
Wheels & Brakes
Front Tire Size
110/80 ZR19
Rear Wheel/Rim Size
4.00 x 17
Rear Tire Size
150/70 ZR17
Front Brakes
2 x 305mm discs, 4 piston caliper
Rear Brakes
Single 265 mm disc, 2 piston caliper
Dimension & Weights
Wheelbase
59.3 inches / 1507 mm
Fuel Tank Capacity
8.7 US gallons / 33.0 L
Dry Weight
223kg / 492 lbs
Features
Four stroke, two cylinder horizontally opposed Boxer engine
4 valves per cylinder
Electronic intake pipe injection
Digital engine management: BMS-K with overrun fuel cutoff
Dual ignition
6-speed transmission
1st gear ratio: 1.583
2nd gear ratio: 1.259
3rd gear ratio: 1.033
4th gear ratio: 0.903
5th gear ratio: 0.903
6th gear ratio: 0.805:1
Telelever suspension
Stanchion diameter: 41mm
Central spring strut
Spring preload 9 times mechanically adjustable
Die-cast aluminium single-sided swinging arm
BMW Motorrad Paralever
WAD strut (travel-related damping)
Spring pre-load hydraulically adjustable
Rebound damping adjustable
33-litre (7.3 Imp gal) fuel tank
New windshield for enhanced protection from wind and weather
Adjustable seat height
Robust tank and engine protection hoops
Extra-wide rider footrests
Adjustable gearshift and brake levers
Maximum output: 74 kW/100 hp at 7,000 rpm
Peak torque: 115 Nm/85 lb-ft at 5,500 rpm
