The BMW R 1200 GS is a tour de force of motorcycle engineering, boasting a four-stroke, two-cylinder Boxer engine with electronic intake pipe injection and digital engine management.
Its engine character is a symphony of power and control, with a smooth, linear delivery of torque that belies its impressive 95hp output.
As you twist the throttle, the R 1200 GS devours the tarmac with ease, its Telelever front suspension and Paralever rear providing a level of comfort and control that’s simply unparalleled in this class.
Whether carving through twisties or devouring miles on the open road, the R 1200 GS is a masterclass in chassis dynamics, its unique blend of off-road capability and on-road finesse making it the ultimate adventure machine.
Its low weight of just 225 kg is a testament to its lightweight yet robust construction, and its incredible handling and agility make it a joy to ride on even the most challenging terrain.
The BMW R 1200 GS is a truly exceptional motorcycle, one that redefines the boundaries of what’s possible on two wheels, and promises an unparalleled riding experience that will leave you breathless and wanting more.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Capacity
1170 cc / 71.4 in.
Max Power
72 kw / 98 hp
Max Torque
115 Nm / 11.7 kgf-m / 84.8 ft-lbs @ 5500 rpm
Fuel Tank Capacity
5.2 US gallons / 20.0 L
Weight (Wet/Kerb)
496 lbs / 225 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1200GS
Year
2005
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Telelever, stanchion ∅41mm, central spring strut, spring preload 9 times mechanically adjustable.
Front Suspension Travel
7.5 inches / 190 mm
Rear Suspension
Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever, WAD strut (travel-related damping), spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, rebound damping adjustable.
Rear Suspension Travel
7.9 inches / 200 mm
Trail
101 mm / 4.0 in
Wheels & Brakes
Front Tire Size
110/80 ZR19
Rear Tire Size
150/70 ZR17
Front Brakes
2 x ∅305mm discs, 4 piston caliper
Rear Brakes
Single ∅265 mm disc, 2 piston caliper
Dimension & Weights
Overall Length
2210 mm / 87.0 in
Overall Width
915 mm / 36.0 in (incl. mirrors)
Overall Height
1450 mm / 57.1 in (excl. mirrors)
Wheelbase
59.3 inches / 1507 mm
Fuel Tank Capacity
5.2 US gallons / 20.0 L
Wet (kerb/curb) Weight
496 lbs / 225 kg
Dry Weight
199 kg / 439 lbs
Features
Four stroke, two cylinder horizontally opposed Boxer engine
4 valves per cylinder
Electronic intake pipe injection and digital engine management
BMS-K with overrun fuel cutoff
Dual ignition
6-speed transmission
1st gear ratio: 1.583
2nd gear ratio: 1.259
3rd gear ratio: 1.033
4th gear ratio: 0.903
5th gear ratio: 0.903
6th gear ratio: 0.805:1
Telelever suspension
41mm stanchion
Central spring strut
Spring preload 9 times mechanically adjustable
Die-cast aluminium single-sided swinging arm
BMW Motorrad Paralever
WAD strut (travel-related damping)
Spring preload hydraulically adjustable
Rebound damping adjustable
Weight: 225 kg or 496 lb
High-performance brakes
BMW Motorcycle Integral ABS
Fully controlled three-way catalytic converter
Integrated knock control
Separate oxygen sensors for each cylinder
Maintenance-free driveshaft
