The BMW R 1150GS Adventure is a machine that embodies the very essence of adventure, beckoning riders to explore the uncharted territories of the world. Its 85 horsepower, two-cylinder Boxer engine delivers a unique riding experience, where the thrill of the journey is as much a part of the ride as the destination.
With its Telelever front suspension and Paralever rear suspension, this bike is designed to take on the toughest terrain with ease, while its robust underbody protection and longer spring travel ensure that even the most arduous journeys are tackled with confidence.
Whether navigating the dusty trails of the Sahara or the mountain passes of the Himalayas, the R 1150GS Adventure is the perfect companion for any rider seeking to push beyond the boundaries of their comfort zone.
And with its promise of adventure fulfilled, this bike leaves no doubt: the thrill of the ride is only the beginning, and the journey itself is the ultimate destination.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Capacity
1130 cc / 69 cu in
Max Power
62.5 kw / 85 hp
Max Torque
98 Nm / 10.0 kgf-m / 71 lb-ft @ 5250 rpm
Fuel Tank Capacity
30Litres / 7.9 US US gal
Weight (Wet/Kerb)
570 lbs / 258 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1150GS Adventure
Year
2004
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Displacement
1130 cc / 69 cu in
Bore x Stroke
101 x 70.5 mm
Compression Ratio
10.3:1
Max Horsepower
62.5 kw / 85 hp
Max Torque
98 Nm / 10.0 kgf-m / 71 lb-ft @ 5250 rpm
Engine Management System
Bosch Motronic MA 2.4 Fuel injection
Lubrication System
Wet sump
Cooling System
Air/Oil cooled
Performance
Top Speed
190 km/h / 118 mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Single disc dry clutch, hydraulically operated
Gearbox
6 Speed
Final Drive
Shaft
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Three section composite frame consisting of front & rear section, load bearing engine
Front Suspension
Light. Telelever with central spring strut, progressive coil spring, twin-tube gas-filled shock,
Front Suspension Travel
8.2 inches / 210 mm
Rear Suspension
Patented BMW Paralever swing arm & shaft drive, single shock with variable rebound and damping adjustments
Rear Suspension Travel
8.6 inches / 220 mm
Rake
26.2
Trail
121 mm / 4.8 in
Wheels & Brakes
Wheels
Cross spoke wheels
Front Wheel/Rim Size
2.50 x 19
Front Tire Size
110/80 R19
Rear Wheel/Rim Size
4.00 x 17
Rear Tire Size
150/70 R17
Front Brakes
2 x 304mm discs, 4 piston calipers
Rear Brakes
Single 276mm disc, 2 piston caliper
Dimension & Weights
Wheelbase
59.1 inches / 1.501 mm
Fuel Tank Capacity
30Litres / 7.9 US US gal
Wet (kerb/curb) Weight
570 lbs / 258 kg
Dry Weight
232 kg / 511 lbs
Features
Four stroke, two cylinder horizontally opposed Boxer engine
4 valves per cylinder
62.5 kW / 85 hp@ 6750 rpm (rear tyre 58.9 kW / 79 hp @ 6750 rpm)
Telelever suspension with central spring strut
Progressive coil spring
Twin-tube gas-filled shock absorber
Patented BMW Paralever swing arm
Shaft drive
Single shock absorber with variable rebound and damping adjustments
Long travel suspension
Robust underbody protection
Special seat
Fall bracket
Short first gear
Large 30 litre fuel tank
Aluminium carrier
Top case
Additional headlamp
RON 91 suitability
