The BMW R 1100GS is a motorcycle that defies conventional logic. Its underpowered 1085cc Boxer twin may only muster 70bhp at the rear wheel, but it compensates with an impressive torque output, making it a short-shifting specialist rather than a rev-hungry sprinter.
This is a bike for navigating twisty roads with precision and control, not for pushing the boundaries of speed. The five-speed gearbox may be a bit buzzy in top gear, but it’s a minor quibble in a machine that’s designed for comfort and durability.
The BMW Telelever and Paralever suspension arrangement is a masterclass in engineering, providing exceptional handling and stability, while the sublime brakes and available ABS ensure confidence-inspiring stops. With its robust build quality and impressive off-road capability, the BMW R 1100GS is the ultimate adventure motorcycle, perfect for tackling the toughest terrain with ease and precision.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Capacity
1084 cc / 66.1 cu in
Max Power
59 kw / 80 hp
Max Torque
97Nm / 9.9 kgf-m / 71 lb-ft / @ 5250 rpm
Fuel Tank Capacity
24 Liters / US 6.3 gal
Weight (Wet/Kerb)
549 lbs / 240 kg
Seat Height
33.0 inches / 840 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1100GS
Year
1997
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Three piece (front and rear sections with load-bearing engine)
Front Suspension
BMW Telelever Single gas-filled shock absorber with progressive coil spring, Preload adjustment (five steps)
Rear Suspension
BMW Paralever (single-sided swinging arm) Single gas-filled shock absorber with coil spring, Preload adjustment (continuously adjustable by handwheel), Rebound damping (continuously adjustable by screw)
Rear Suspension Travel
7.9 inches / 200 mm
Wheels & Brakes
Front Wheel/Rim Size
4 x 17 inch patented cross spoke
Front Tire Size
110/80 R19
Rear Tire Size
150/70 R17
Front Brakes
2 x ∅297mm Discs, 3 piston calipers
Rear Brakes
Single ∅250mm disc, 3 piston caliper
Dimension & Weights
Seat Height
33.0 inches / 840 mm
Wheelbase
59.4 inches / 1509 mm
Ground Clearance
200 mm / 7.8 in
Fuel Tank Capacity
24 Liters / US 6.3 gal
Wet (kerb/curb) Weight
549 lbs / 240 kg
Dry Weight
225 kg / 496.0 lbs
Features
Bosch Motronic 2.2 with fuel cutoff when coasting
Electronic MA 2.2 controlled by Bosch Motronic
BMW Telelever
Single gas-filled shock absorber with progressive coil spring
Preload adjustment (five steps)
BMW Paralever (single-sided swinging arm)
Single gas-filled shock absorber with coil spring
Preload adjustment (continuously adjustable by handwheel)
Rebound damping (continuously adjustable by screw)
Oil/air-cooled 1085cc Boxer twin engine
70bhp at the back wheel
Torque output almost equal to horsepower
Five-speed gearbox
ABS system
Sublime brakes
