The BMW R 1100GS – a motorcycle that defies convention with its unique blend of power, character, and riding experience. Equipped with the Bosch Motronic 2.2 fuel injection system, the 1085cc Boxer twin engine delivers a punchy 70bhp, but it’s the torque output that truly sets it apart, making it an ideal companion for long-distance travel.
Its engine character is perfectly suited for the task at hand – a gentle, reassuring growl that encourages short-shifting and a more relaxed approach to cornering. The BMW R 1100GS is not a high-revving, performance-focused machine, but rather a comfortable, go-anywhere adventure bike that’s designed to get you to your destination in style.
The suspension arrangement may look unconventional, but it works beautifully, providing exceptional stability and control, especially when braking. And with the addition of ABS, you can ride with complete confidence, knowing that you have the best possible safety features at your disposal. The BMW R 1100GS is a motorcycle that’s all about substance over style, and it’s an excellent choice for anyone seeking a reliable, capable, and enjoyable long-distance companion. It’s a motorcycle that will take you on the journey of a lifetime, and one that you’ll never forget.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Capacity
1084 cc / 66.1 cu in
Max Power
59 kw / 80 hp
Max Torque
97Nm / 9.9 kgf-m / 71 lb-ft / @ 5250 rpm
Fuel Tank Capacity
24 Liters / US 6.3 gal
Weight (Wet/Kerb)
549 lbs / 240 kg
Seat Height
33.0 inches / 840 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 1100GS
Year
1996
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Three piece (front and rear sections with load-bearing engine)
Front Suspension
BMW Telelever Single gas-filled shock absorber with progressive coil spring, Preload adjustment (five steps)
Rear Suspension
BMW Paralever (single-sided swinging arm) Single gas-filled shock absorber with coil spring, Preload adjustment (continuously adjustable by handwheel), Rebound damping (continuously adjustable by screw)
Rear Suspension Travel
7.9 inches / 200 mm
Wheels & Brakes
Front Wheel/Rim Size
4 x 17 inch patented cross spoke
Front Tire Size
110/80 R19
Rear Tire Size
150/70 R17
Front Brakes
2 x ∅297mm Discs, 3 piston calipers
Rear Brakes
Single ∅250mm disc, 3 piston caliper
Dimension & Weights
Seat Height
33.0 inches / 840 mm
Wheelbase
59.4 inches / 1509 mm
Ground Clearance
200 mm / 7.8 in
Fuel Tank Capacity
24 Liters / US 6.3 gal
Wet (kerb/curb) Weight
549 lbs / 240 kg
Dry Weight
225 kg / 496.0 lbs
Features
Bosch Motronic 2.2 with fuel cutoff when coasting
Electronic MA 2.2 control
BMW Telelever
Single gas-filled shock absorber with progressive coil spring
Preload adjustment (five steps)
BMW Paralever (single-sided swinging arm)
Single gas-filled shock absorber with coil spring
Preload adjustment (continuously adjustable by handwheel)
Rebound damping (continuously adjustable by screw)
Oil/air-cooled 1085cc Boxer twin engine
70bhp at the back wheel
Torque output almost equal to horsepower
Five ratios gearbox
ABS brakes
Sublime brakes
