The BMW R11, a motorcycle that embodies the essence of pre-war engineering, boasts a single carburetor type BMW ∅24 mm. This sleek setup was later replaced with the Amal 6/406 SP and 6/407 SP models in 1933, further refining the machine’s performance.
Its powertrain is driven by a Bosch Magneto generator D2L or Magneto Ignition FF2, delivering a respectable 13.4 kW / 18hp at 3400 rpm. This output increases to 14.9 kW / 20hp at 4400 rpm in 1933, offering a thrilling riding experience.
As you twist the throttle, the BMW R11 comes alive, its engine character defined by a smooth, responsive delivery that’s both captivating and exhilarating.
Key Specifications
Engine Type
Four stroke,two cylinder flat twin, Side valve
Engine Capacity
745 cc / 45.5 cu in.
Max Power
13.4 kw / 18 hp
Fuel Tank Capacity
14 L / 3.7 US gal
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 11
Year
1929 – 2034
Engine
Engine Type
Four stroke,two cylinder flat twin, Side valve
Displacement
745 cc / 45.5 cu in.
Bore x Stroke
78 x 78 mm
Compression Ratio
5.5:1
Max Horsepower
13.4 kw / 18 hp
Engine Management System
Single carburetor type BMW ∅24 mm (1933: 1 x carburetor type Amal 6/406 SP and 6/407 SP)
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Single plate dry clutch
Gearbox
3 Speed
Gear Ratios
1st 2.83 / 2nd 1.55 / 3rd 1.08:1
Final Drive
Shaft
Electrical & Electronics System
Starter
Kick
Chassis & Suspension
Frame Type
Twin loop pressed steel frame
Front Suspension
Plate spring 9 laminae
Rear Suspension
Rigid, spring loaded saddle
Wheels & Brakes
Rear Brakes
∅37mm Cardan brake
Dimension & Weights
Fuel Tank Capacity
14 L / 3.7 US gal
Features
Single carburetor type BMW ∅24 mm
Bosch Magneto generator D2L
Magneto Ignition FF2
13.4 kW / 18hp engine output
3400 rpm engine speed
14.9 kW / 20hp engine output (1933 model)
