BMW R 100R Mystic (1993)

BMW R 100R Mystic (1993)

The BMW R 100R Mystic is a bike that defies categorization, blending the best of old and new to create a truly unique riding experience. Powered by a revamped 1000cc boxer engine, the R 100R boasts impressive performance, with a smooth and linear power delivery that belies its age. The addition of Japanese Showa suspension and Brembo brakes adds a touch of modernity to the bike’s classic lines, while the 40mm Bing carbs and emissions afterburning circuit demonstrate BMW’s commitment to innovation.

With its distinctive rounded-off valve covers and retro-inspired design, the R 100R is a bike that’s sure to turn heads on the road. But it’s not just about looks – the R 100R is also a seriously capable machine, with a Paralever rear suspension system and a range of advanced rider aids. Whether you’re a seasoned motorcyclist or just looking for a unique ride, the BMW R 100R Mystic is a bike that’s sure to deliver.

The result of BMW’s experimental approach to motorcycle design, the R 100R is a bike that’s equal parts retro and revolutionary. With its blend of old-school charm and cutting-edge technology, it’s a machine that’s truly one-of-a-kind, and a testament to the company’s willingness to push the boundaries of what’s possible. And with its advanced features and capabilities, the R 100R is a bike that’s sure to remain relevant for years to come.

Key Specifications

Engine TypeFour stroke, two cylinder horizontally opposed Boxer, 2 valves per cylinder.
Engine Capacity980 cc / 59.8 cub in.
Max Power44 kw / 60 hp
Max Torque76 Nm / 7.75 kgf-m / 56 ft lb @ 3750 rpm
Fuel Tank Capacity5.7 US gallons / 22.0 L
Weight (Wet/Kerb)469 lbs / 213 kg
Seat Height31.5 inches / 800 mm
BMW R 100R Mystic (1993)

All Specifications

Make & Model

ModelBMW R 100R Mystic
Year1993

Engine

Engine TypeFour stroke, two cylinder horizontally opposed Boxer, 2 valves per cylinder.
Displacement980 cc / 59.8 cub in.
Bore x Stroke94 x 70.6 mm
Compression Ratio8.5:1
Max Horsepower44 kw / 60 hp
Max Torque76 Nm / 7.75 kgf-m / 56 ft lb @ 3750 rpm
Engine Management System2 Constant depression carburettors, Bing 94/40/123 – 94/40/124
Lubrication SystemWet sump
Cooling SystemAir/oil cooled

Performance

Top Speed175 km/h / 109 mph

Transmission

ClutchDry single plate, with lever action diaphragm spring
Gearbox5 Speed
Gear Ratios1st 4.40 / 2nd 2.86 / 3rd 2.07 / 4th 1.67 / 5th 1.50:1
Final DriveShaft

Electrical & Electronics System

Battery12V 25Ah
StarterElectric

Chassis & Suspension

Frame TypeDouble loop tubular frame with bolt on rear section
Front SuspensionTelescopic fork with hydraulic shock absorber, Showa, ∅41 mm
Rear SuspensionParalever swinging arm, single shock, Showa, adjustable for rebound damping
Rake28.5
Trail99 mm / 3.9 in.

Wheels & Brakes

Front Tire Size110 / 80 V18, Metzeler ME33 Lazer
Rear Tire Size140 / 80 V 17, Metzeler ME55A Metronic
Front Brakes2 x ∅285mm disc 4 piston calipers
Rear BrakesSingle ∅200mm disc

Dimension & Weights

Seat Height31.5 inches / 800 mm
Wheelbase58.8 inches / 1494 mm
Ground Clearance170 mm / 6.7 in.
Fuel Tank Capacity5.7 US gallons / 22.0 L
Wet (kerb/curb) Weight469 lbs / 213 kg
Dry Weight197kg / 435 lbs

Features

  • Dry single plate clutch
  • Lever action diaphragm spring
  • 5-speed gearbox
  • 980cc Paris-Dakar inspired GS motor
  • 60bhp at 6500rpm
  • 56lb-ft at 3750rpm
  • GS big-bore carbs
  • 40mm Bing carbs
  • Emissions afterburning circuit
  • Paralever
  • Floating discs
  • 8 Brembo pistons
  • 40mm Showa suspension
  • Adjustable rear shock absorber
  • 18 and 17 inch wheels
  • Road suspension
  • Narrow handlebars
