The BMW R 100R is a thought-provoking exercise in contrasts, blending the old with the new in a way that’s uniquely BMW. At its heart lies a 1000cc boxer engine, a design dating back to the 1920s, yet updated with modern fuel injection and an emissions afterburning circuit. Paired with Showa suspension and Brembo brakes, this retro-styled bike is anything but antiquated.

Its rounded-off valve covers and distinctive design make the R 100R a true standout in the world of motorcycling. The 40mm Bing carbs provide a perfect blend of power and control, while the paralever and electronic diagnostic equipment add a layer of sophistication. Whether you’re drawn to its nostalgic charm or its cutting-edge technology, the R 100R is an experience unlike any other.

The result is a bike that defies categorization, sitting comfortably in the space between old and new, retro and modern. With its unique blend of heritage and innovation, the BMW R 100R is a true original, a testament to the brand’s willingness to push boundaries and challenge conventional wisdom. It’s a bike that will leave you questioning what a motorcycle should be.

Key Specifications

Engine TypeFour stroke, two cylinder horizontally opposed Boxer, 2 valves per cylinder.
Engine Capacity980 cc / 59.8 cub in.
Max Power44 kw / 60 hp
Max Torque76 Nm / 7.75 kgf-m / 56 ft lb @ 3750 rpm
Fuel Tank Capacity5.7 US gallons / 22.0 L
Weight (Wet/Kerb)469 lbs / 213 kg
Seat Height31.5 inches / 800 mm
BMW R 100R (1991 - 92)

All Specifications

Make & Model

ModelBMW R 100R
Year1991 – 92

Engine

Engine TypeFour stroke, two cylinder horizontally opposed Boxer, 2 valves per cylinder.
Displacement980 cc / 59.8 cub in.
Bore x Stroke94 x 70.6 mm
Compression Ratio8.5:1
Max Horsepower44 kw / 60 hp
Max Torque76 Nm / 7.75 kgf-m / 56 ft lb @ 3750 rpm
Engine Management System2 Constant depression carburettors, Bing 94/40/123 – 94/40/124
Lubrication SystemWet sump
Cooling SystemAir/oil cooled

Performance

Top Speed175 km/h / 109 mph

Transmission

ClutchDry single plate, with lever action diaphragm spring
Gearbox5 Speed
Gear Ratios1st 4.40 / 2nd 2.86 / 3rd 2.07 / 4th 1.67 / 5th 1.50:1
Final DriveShaft

Electrical & Electronics System

Battery12V 25Ah
StarterElectric

Chassis & Suspension

Frame TypeDouble loop tubular frame with bolt on rear section
Front SuspensionTelescopic fork with hydraulic shock absorber, Showa, ∅41 mm
Rear SuspensionParalever swinging arm, single shock, Showa, adjustable for rebound damping
Rake28.5
Trail99 mm / 3.9 in.

Wheels & Brakes

Front Tire Size110 / 80 V18, Metzeler ME33 Lazer
Rear Tire Size140 / 80 V 17, Metzeler ME55A Metronic
Front Brakes2 x ∅285mm disc 4 piston calipers
Rear BrakesSingle ∅200mm disc

Dimension & Weights

Seat Height31.5 inches / 800 mm
Wheelbase58.8 inches / 1494 mm
Ground Clearance170 mm / 6.7 in.
Fuel Tank Capacity5.7 US gallons / 22.0 L
Wet (kerb/curb) Weight469 lbs / 213 kg
Dry Weight197kg / 435 lbs

Features

  • Dry single plate clutch
  • Telescopic fork with hydraulic shock absorber
  • Showa suspension
  • 40mm Bing carbs
  • Emissions afterburning circuit
  • Paralever
  • Electronic diagnostic equipment socket
  • Liquid-cooled four-valve flat-twin engine (coming next year)
  • 980cc Paris-Dakar inspired GS motor
  • Five-speed gearbox
  • GS big-bore carbs
  • 60 bhp at 6500rpm
  • 56 lb.ft torque at 3750rpm
  • Double-loop steel frame
  • GS-style wheelbase, rake, and trail
  • 18 and 17 inch wheels
  • Road suspension
  • Narrow handlebars
  • Japanese-style forks with recalculated spring and damping rates
  • Rear suspension with adjustable rebound damping and preload
