BMW K 1600 GTL (2022)

BMW K 1600 GTL (2022)

The BMW K 1600 GTL is a masterclass in luxury touring motorcycles, boasting an exceptional blend of style, comfort, and high-performance capabilities. Its revised six-cylinder in-line engine is now compliant with EU-5 regulations, featuring improved emission values, increased power, and torque.

At the heart of this magnificent machine lies the BMS-O engine control system, complemented by two knock sensors and broadband lambda probes. This cutting-edge technology not only ensures optimal performance but also provides an unparalleled riding experience.

As you settle into the GTL’s comfortable ergonomics and standard topcase, you’ll feel a sense of liberation that’s hard to find in any other motorcycle. The six-cylinder engine purrs smoothly beneath you, its torque-rich characteristics making long-distance touring a breeze. And yet, it’s not just about comfort – this bike is also designed for thrill-seekers, with a level of agility and handling that belies its size.

The result is an unforgettable riding experience that will leave even the most seasoned enthusiasts grinning from ear to ear. With the BMW K 1600 GTL, every journey becomes a thrilling adventure, and every moment on the road is savored in absolute comfort and style – making it the ultimate luxury touring motorcycle for riders who crave the perfect blend of power, elegance, and freedom.

Key Specifications

Engine TypeFour stroke, transverse six cylinder, 4 valves per cylinder
Engine Capacity100.6 cubic inches / 1649 cc
Max Power118 kw / 160 hp
Max Torque132.7 ft-lb / 180 nm
Fuel Tank Capacity7.0 US gallons / 26.5 L
Weight (Wet/Kerb)789.2 lbs / 358 kg
Seat Height29.5 inches / 800 mm
BMW K 1600 GTL (2022)

All Specifications

Make & Model

ModelBMW K 1600 GTL
Year2022

Engine

Engine TypeFour stroke, transverse six cylinder, 4 valves per cylinder
Displacement100.6 cubic inches / 1649 cc
Bore x Stroke72 x 67.5 mm
Compression Ratio12.2:1
Max Horsepower118 kw / 160 hp
Max Torque132.7 ft-lb / 180 nm
Cooling SystemLiquid cooled

Performance

Top Speedn/a

Transmission

ClutchMultiple-disc clutch in oil bath
Gearbox6-speed gearbox, helical cut
Gear Ratios1st 2.23 / 2nd 1.641 / 3rd 1.319 / 4th 1.101 / 5th 0.926 / 6th 0.788
Final DriveShaft

Electrical & Electronics System

StarterElectric
ABSBMW Motorrad ABS Pro (partial integral, slant-layer-optimized)

Chassis & Suspension

Frame TypeBridge-type frame, cast aluminium, load-bearing engine
Front SuspensionBMW Motorrad Duolever; central spring strut
Front Suspension Travel4.5 inches / 114.3 mm
Rear SuspensionCast aluminum single-sided swing arm with BMW Motorrad Paralever; central spring strut
Rear Suspension Travel5.3 inches / 135 mm
Trail62.2

Wheels & Brakes

WheelsCast aluminium wheels
Front Wheel/Rim Size3.0 x 17
Front Tire Size120/70 ZR17
Rear Wheel/Rim Size6.00 x 17
Rear Tire Size190/55 ZR17
Front Brakes2 x 320mm discs, 4 piston calipers
Rear BrakesSingle 320mm disc, 2 piston caliper
ABSBMW Motorrad ABS Pro (partial integral, slant-layer-optimized)

Dimension & Weights

Overall Length2489 m / 97.9 in
Overall Width1000 mm / 39.4 in
Overall Height1440 mm – 1597 mm / 56.7 in – 62.9 in
Seat Height29.5 inches / 800 mm
Wheelbase63.7 inches / 1618 mm
Fuel Tank Capacity7.0 US gallons / 26.5 L
Wet (kerb/curb) Weight789.2 lbs / 358 kg

Features

  • Electronic intake pipe injection digital engine management system: BMS-O with throttle-by-wire
  • Six-cylinder in-line engines
  • Bridge-type frame, cast aluminium, load-bearing engine
  • Throttle-by-wire technology
  • Improved emission values
  • Increased power output (118 kW / 160 hp at 6,750 rpm)
  • Increased torque output (180 Nm at 5,250 rpm)
  • Engine drag torque control (MSR) for stable riding conditions
  • Dynamic ESA Next Generation electronic suspension with fully automatic load compensation
  • Automatic load adjustment and damping adjustment
  • Six-cylinder in-line engine with new engine control
  • Knock sensor system
  • Two additional broadband lambda probes
  • Standard topcase on K 1600 GTL model
  • Exclusive equipment features on K 1600 Grand America model
