BMW K 1600 GTL (2019 – 2020)

BMW K 1600 GTL (2019 - 2020)

The BMW K 1600 GTL is the epitome of luxury touring motorcycles, boasting a stunning bridge-type frame and cast aluminium construction that exudes elegance and sophistication. At the heart of this magnificent machine lies the legendary six-cylinder in-line engine, delivering impressive performance with effortless ease.

The latest generation of Dynamic ESA and ABS Pro ensures unparalleled comfort and safety, while the redesigned panels reinforce its sleek appearance. Whether cruising through calm weather or navigating treacherous terrain, the K 1600 GTL’s exceptional Dynamic ESA suspension and MW Motorrad Integral ABS guarantee a smooth and secure ride.

With its impressive array of standard features, including heated grips and seats, one-piece seat, and built-in side panniers, the K 1600 GTL redefines luxury travel on two wheels. Experience the ultimate in touring comfort and performance with the BMW K 1600 GTL.

Key Specifications

Engine TypeFour stroke, transverse six cylinder, 4 valves per cylinder
Engine Capacity1649 cc / 100.6 cu in.
Max Power118 kw / 160.5 hp
Max Torque175 Nm / 17.8 kgf-m / 129 lb-ft @ 5250 rpm
Fuel Tank Capacity7.0 US gallons / 26.5 L
Weight (Wet/Kerb)348.0 kg / 767.2 in
Seat Height29.5 inches / 750 mm
BMW K 1600 GTL (2019 - 2020)

All Specifications

Make & Model

ModelBMW K 1600 GTL
Year2019 – 2020

Engine

Engine TypeFour stroke, transverse six cylinder, 4 valves per cylinder
Displacement1649 cc / 100.6 cu in.
Bore x Stroke72 x 67.5 mm
Compression Ratio12.2:1
Max Horsepower118 kw / 160.5 hp
Max Torque175 Nm / 17.8 kgf-m / 129 lb-ft @ 5250 rpm
Engine Management System52mm Throttle valve diameter, BMS-X
Cooling SystemLiquid cooled
FuelPremium unleaded (95 RON)

Performance

Top Speedn/a

Transmission

ClutchMultiplate wet clutch, hydraulically activated
GearboxConstant-mesh 6-speed gearbox, helical cut
Gear Ratios1st 2.23 / 2nd 1.641 / 3rd 1.319 / 4th 1.101 / 5th 0.926 / 6th 0.788
Final DriveShaft

Electrical & Electronics System

Battery12 V / 19 Ah maintenance free
StarterElectric
ABSBMW Motorrad ABS (partial integral)

Chassis & Suspension

Frame TypeBridge-type frame, cast aluminium, load-bearing engine
Front SuspensionDual longitudinal control arm, Dynamic ESA semi-active suspension (road and dynamic modes)
Front Suspension Travel4.9 inches / 115 mm
Rear SuspensionParalever (single-sided swing arm), central spring strut, rebound/continuously variable, Dynamic ESA semi-active suspension (road and dynamic modes)
Rear Suspension Travel5.3 inches / 135 mm
Trail62.2

Wheels & Brakes

WheelsCast aluminium wheels
Front Wheel/Rim Size3.0 x 17
Front Tire Size120/70 ZR17
Rear Wheel/Rim Size6.00 x 17
Rear Tire Size190/55 ZR17
Front Brakes2 x 320mm discs, 4 piston calipers
Rear BrakesSingle 320mm disc, 2 piston caliper
ABSBMW Motorrad ABS (partial integral)

Dimension & Weights

Seat Height29.5 inches / 750 mm
Wheelbase66.1 inches / 1680 mm
Fuel Tank Capacity7.0 US gallons / 26.5 L
Wet (kerb/curb) Weight348.0 kg / 767.2 in
Dry Weight321 kg / 707.7 lbs

Features

  • Bridge-type frame, cast aluminium, load-bearing engine
  • 6-cylinder in-line engine
  • Dynamic ESA (Electronic Suspension Adjustment)
  • ABS Pro
  • MW Motorrad Integral ABS with control regardless of lean angle
  • DTC (Dynamic Traction Control)
  • Steplessly adjustable electric comfort windscreen
  • Cruise control
  • Keyless ride
  • Heated grips and seats
  • One-piece seat
  • Comfort foot pegs
  • Built-in side panniers
  • Detachable top box with backrest
  • Centre stand
  • Pro shift assist
  • Tire pressure monitoring
  • One key system for ignition, steering, fuel filler cap, storage compartments, panniers, and seat locks
  • Central locking system
  • Anti-theft alarm system
  • Integrated ignition and steering lock
  • Adjustable brake and clutch levers
  • Lockable storage compartment and on-board literature
  • On-board computer
  • Multifunctional display
  • Instrument cluster with chrome accents and indirect dial light
  • Xenon headlights
  • Adaptive headlight
  • Multifunctional display with on-board computer and audio system operated using the multi-controller
  • Audio system with navigation device preparation
  • Reverse assistant
  • Self-energizing clutch requiring only a small amount of force
  • 3 riding modes: Rain, Road, and Dynamic
  • Hill start control
  • Chrome kit for body
  • Lights permanently illuminated
