The BMW HP4 is a masterclass in performance engineering, distilling the essence of the S 1000 RR into a razor-sharp, 193 horsepower package that tips the scales at just 373 pounds.
Built around a cutting-edge 4-cylinder engine and paired with the latest digital motor electronics, the HP4 is a force to be reckoned with on both the track and the twisties.
With a dry weight of just 373 pounds and a 90% full fuel tank weighing in at 439 pounds, this is a motorcycle that demands to be ridden with precision and finesse.
The HP4 is not just a bike, it’s an experience – a symphony of power, handling, and dynamics that will leave even the most seasoned riders grinning from ear to ear.
Key Specifications
Engine Type
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Engine Capacity
61 cubic inches / 999 cc
Max Power
144 kw / 193 hp
Max Torque
112 Nm / 11.4 kgf-m / 82.6 lb-ft @ 9750 rpm
Fuel Tank Capacity
17.5 Litres / US 4.6 gal
Weight (Wet/Kerb)
439 lbs / 199 kg
Seat Height
33.3 inches / 820 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW HP 4
Year
2014
Engine
Engine Type
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Displacement
61 cubic inches / 999 cc
Bore x Stroke
80 x 49,7 mm
Compression Ratio
13:1
Max Horsepower
144 kw / 193 hp
Max Torque
112 Nm / 11.4 kgf-m / 82.6 lb-ft @ 9750 rpm
Engine Management System
Electronic fuel injection, digital motor electronics BMS-KP
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Multiple disc antihopping clutch in oil bath, mechanically operated
BMW Motorrad Race ABS (partially integral, disengageable)
Chassis & Suspension
Frame Type
Bridge-type aluminium frame, load-bearing engine
Front Suspension
USD fork with DEC, fixed fork tube diameter 46 mm damping electronically adjustable, spring preload adjustable
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Aluminum double-sided swing arm with DDC central spring strut, compression and rebound stage electronically adjustable, spring preload hydraulicaily adjustable
Rear Suspension Travel
5.1 inches / 130 mm
Rake
24.0
Trail
99 mm / 3.9 in
Wheels & Brakes
Front Wheel/Rim Size
3.50×17 Forged light alloy, 7 spoke
Front Tire Size
120/70 ZR17
Rear Wheel/Rim Size
6.00 x 17 Forged light alloy, 7 spoke
Rear Tire Size
200/55 ZR17
Front Brakes
2 x 320mm discs radial monoblock, 4-piston fixed caliper
Rear Brakes
Single 220mm disc, 1 piston floating caliper
ABS
BMW Motorrad Race ABS (partially integral, disengageable)
Dimension & Weights
Overall Length
2056 mm / 80.9 in
Overall Width
826 mm / 32.5 in (incl. mirrors)
Overall Height
1138 mm / 44.8 in (excl. mirrors)
Seat Height
33.3 inches / 820 mm
Wheelbase
56 inches / 1422 mm
Fuel Tank Capacity
17.5 Litres / US 4.6 gal
Wet (kerb/curb) Weight
439 lbs / 199 kg
Dry Weight
169 kg / 373 lbs
Features
Electronic fuel injection
Digital motor electronics BMS-KP
4-cylinder engine
1000cc class
193 hp (142kW) output
373 lbs (169 kg) dry weight
439 lbs (199 kg) with 90% full fuel tank
Race ABS
Dynamic Traction Control (DTC)
Dynamic Damping Control (DDC)
Upside-down fork
Spring strut
Passenger seat cover (standard)
Passenger package (factory production option)
Monoposto design
Homologation basis for motorcycle racing
Superbike and superstock category
High-quality materials
Intelligent technology
Customizable to specific riding conditions
