BMW F 800GS Adventure (2017)

BMW F 800GS Adventure (2017)

The BMW F 800GS Adventure has been refined for 2017, building on its already impressive versatility and accessible seat height. The 798cc parallel-twin engine, now meeting EU4 regulations, remains a highlight with its accessible power delivery and excellent fuel efficiency. A key update is the electromotive throttle controller, which provides even finer control and improved response.

Riding modes have been expanded to include Rain and Road, ideal for damp or dry surfaces, while Enduro and Enduro Pro modes are available as an option for off-road enthusiasts. The new instrument cluster boasts redesigned dials and additional information, including riding mode details.

The 2017 F 800GS Adventure also receives styling updates, including a new stainless steel tailpipe, redesigned HP sports exhaust, and galvanized radiator trim elements. The end result is a more refined and feature-packed adventure bike, ready to take on the world’s most challenging roads.

Key Specifications

Engine TypeFour stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Engine Capacity798 cc / 47.7 cub. in.
Max Power62.5 kw / 85 hp
Max Torque80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm
Fuel Tank Capacity6.3 US gallons / 24.0 L
Weight (Wet/Kerb)505 lbs / 229 kg
Seat Height35 inches / 860 mm
BMW F 800GS Adventure (2017)

All Specifications

Make & Model

ModelBMW F 800GS Adventure
Year2017

Engine

Engine TypeFour stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Displacement798 cc / 47.7 cub. in.
Bore x Stroke82 x 75.8 mm
Compression Ratio12.0:1
Max Horsepower62.5 kw / 85 hp
Max Torque80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm
Engine Management SystemElectronic intake injection, ∅45mm throttle bodies
Lubrication SystemDry sump

Performance

Top Speed199.0 km/h / 124 mph

Transmission

ClutchMultiplate-platein oil bath
Gearbox6 Speed
Gear Ratios1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96
Final DriveChain

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular frame in steal partly carrying the engine
Front Suspension43mm Marzocchi upside down forks
Front Suspension Travel9.1 inches / 230 mm
Rear SuspensionDouble strut swing arm aluminium coast in one piece
Rear Suspension Travel8.5 inches / 215 mm
Rake26
Trail117 mm / 4.6 in.

Wheels & Brakes

Wheelsspoke
Front Tire Size90/90 – 21 54V
Rear Tire Size150/70 – 17 69V
Front Brakes2 x ∅300mm discs, 4 piston calipers, ABS
Rear BrakesSingle ∅265mm disc, 2 piston caliper, ABS

Dimension & Weights

Seat Height35 inches / 860 mm
Fuel Tank Capacity6.3 US gallons / 24.0 L
Wet (kerb/curb) Weight505 lbs / 229 kg
Dry Weight214 kg / 472 lbs

Features

  • Newly designed end piece of the stainless steel tailpipe
  • HP sports exhaust by Akrapovič available as an Original BMW Motorrad accessory
  • Electromotive throttle controller for improved response
  • Riding modes Rain and Road as standard
  • Riding modes Enduro and Enduro Pro (only F 800 GS / F 800 GS Adventure) as an ex works option
  • Full E-Gas ride-by-wiresystem for improved response and controllability
  • Instrument panel with new dials, MIL indicator lamp and riding mode display
  • Dynamic paint finish and style concepts
  • Side reflectors on fork slider tubes and fixed fork tubes
  • Newly designed and more easily readable dials
  • Malfunction Indicator Light (MIL) to meet EU4 norm
  • Display extended to include riding mode information
  • Galvanized radiator trim elements (F800GS Adventure only)
  • New intake silencer cover (F800GS Adventure only)
  • New ignition lock casing (F800GS Adventure only)
  • Adaptation to EU4 requirements
  • Parallel-twin 798cc engine
  • EU4 regulations compliance
