Benelli TRK 502 (2016 -)

The Benelli TRK 502 embodies the perfect blend of touring versatility and adventure spirit, inviting riders to turn every day into a new journey. Its powerful twin-cylinder engine produces 48 horsepower at 8500 rpm and 45 Nm of torque at 4500 rpm, ensuring effortless acceleration in all conditions.

Wrapped in a traditional steel trellis frame, the TRK 502 features a range of innovative technologies, including electronic injection, overhead double camshaft timing system, and adjustable upside-down front fork suspension. The bike’s aggressive design is matched by its impressive capabilities, with large fuel tank, high-quality LED headlights, and robust braking performance courtesy of dual 320mm front discs and twin-piston floating calipers.

The TRK 502 offers a unique riding experience that combines comfort, stability, and precision, making it an ideal choice for long-distance touring adventures. With its sleek design, advanced features, and impressive performance capabilities, the Benelli TRK 502 is poised to revolutionize the world of adventure motorcycles, providing riders with the freedom to explore new horizons without compromise.

Key Specifications

Engine Type	Parallel twin, DOHC, 8 valves
Engine Capacity	499.6 cc / 30.5 cu in
Max Torque	45 Nm / 4.59 kgf-m @ 4500 rpm
Fuel Tank Capacity	5.2 US gallons / 19.7 L
Seat Height	32.1 inches / 815 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Benelli TRK 502
Year	2016 –

Engine

Engine Type	Parallel twin, DOHC, 8 valves
Displacement	499.6 cc / 30.5 cu in
Bore x Stroke	69 x 66.8 mm
Compression Ratio	11.5:1
Max Torque	45 Nm / 4.59 kgf-m @ 4500 rpm
Engine Management System	EFI with 37 mm throttle body
Cooling System	Liquid cooled
Exhaust	With catalytic converter and oxygen sensors

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Wet clutch
Gearbox	6-Speed
Final Drive	Chain

Electrical & Electronics System

Starter

Electric

Chassis & Suspension

Frame Type	Steel tube trellis frame
Front Suspension	50 mm USD fork, adjustable
Rear Suspension	Swingarm with monoshock, spring preload adjustable

Wheels & Brakes

Front Wheel/Rim Size	MT 3.50 x 17, Aluminium alloy, cross spoked wheel optional
Front Tire Size	120/70-ZR17, Pirelli Angel dual purpose (110/80-R19 option)
Rear Wheel/Rim Size	MT 4.50 x 17, Aluminium alloy, cross spoked wheel optional
Rear Tire Size	160/60-ZR17, Pirelli Angel dual purpose (150/70-R17 option)
Front Brakes	Dual 320 mm floating discs, 4-piston calipers, ABS
Rear Brakes	Single 260 mm disc, 2-piston caliper, ABS

Dimension & Weights

Overall Length	2180 mm / 85.8 in (option: 2211 mm / 87.0″)
Overall Width	912 mm / 35.9 in
Overall Height	1465 mm / 57.7 in (option: 1495 mm / 58.9″)
Seat Height	32.1 inches / 815 mm
Wheelbase	60.4 inches / 1535 mm
Ground Clearance	230 mm / 9.06 in (option:240 mm / 9.45″)
Fuel Tank Capacity	5.2 US gallons / 19.7 L

Features

Twin-cylinder four-stroke liquid-cooled 500cc engine
Electronic injection system
Overhead double camshaft timing system
4 valves per cylinder
Maximum power: 48 CV (35 kW) at 8500 rpm
Torque: 45 Nm (4.6 kgm) at 4500 rpm
6-speed gearbox
Hydraulic clutch
Adjustable upside down front fork
Swingarm with monoshock rear suspension
Suspension travel of 150mm front and rear
Large front fairing for comfort
Dynamic hand guards for protection
Two front discs, 320 mm in diameter
Two-piston floating caliper front brakes
Rear disc, 260 mm in diameter, with twin piston caliper
17″ aluminum alloy wheels
Pirelli Angel 120/70-17 and 160/60-17 tyres
Aluminum alloy rims (off-road version)
