Benelli Tre-K 1130 (2013 – 2014)

Benelli Tre-K 1130 (2013 - 2014)

The Benelli Tre-K 1130 is a true jack-of-all-trades, effortlessly combining the comfort of a touring bike with the agility and thrill of a sportier machine. Its 3-cylinder engine produces a potent 123.4 horsepower at 9,000 rpm, while delivering a stout 112 Nm of torque at just 5,000 rpm.

The Tre-K’s mixed steel/aluminium frame provides exceptional stability and handling, while its ASD steel tube trellis swingarm and Extreme Technology single shock absorber offer adjustable rebound and spring preload for fine-tuning the ride. The result is an indestructible traveller that can conquer long distances with ease, yet still deliver a thrilling sporting experience.

Whether navigating twisty mountain roads or cruising down the highway, the Tre-K 1130’s exceptional performance and versatility are sure to leave riders grinning from ear to ear. With its advanced electronics, high-quality components, and attention to detail, this Benelli flagship is poised to set new standards in crosstourer excellence.

Key Specifications

Engine TypeFour stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Engine Capacity1130 cc / 69 cu in
Max Power92 kw / 123 hp
Max Torque115 Nm / 11.4 kgm / 67.9 lb-ft @ 6250 rpm
Fuel Tank Capacity5.7 US gallons / 21.5 L
Seat Height31.9 inches / 810 mm
Benelli Tre-K 1130 (2013 - 2014)

All Specifications

Make & Model

ModelBenelli Tre-K 1130
Year2013 – 2014

Engine

Engine TypeFour stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Displacement1130 cc / 69 cu in
Bore x Stroke88 x 62 mm
Compression Ratio11.5:1
Max Horsepower92 kw / 123 hp
Max Torque115 Nm / 11.4 kgm / 67.9 lb-ft @ 6250 rpm
Engine Management SystemElectronic injectionwith1injectorpercylinder
Lubrication SystemWet sump
Cooling SystemLiquid cooled
ExhaustWith catalytic converter and oxygen sensor

Performance

Top Speed221.4 km/h / 137.5 mph

Transmission

ClutchWet clutch with hydraulic command
Gearbox6 Speed
Gear Ratios1st 14/39 / 2nd 18/35 / 3rd 21/32 / 4th 23/30 / 5th 24/28 / 6th 26/27
Final DriveChain drive, ratio 16:37

Electrical & Electronics System

Chassis & Suspension

Frame TypeMixedsolution.Front:ASDsteeltubetrellis,fastenedtoboxedrearsection,aluminiumalloycastings.Subframe:aluminiumdie-cast.
Front SuspensionMarzocchi50mmupsidedownforkdamping, reboundandspringpre-loadadjustment.
Rear SuspensionASD steel tube trellis swingarm with Extreme Technology single shock absorber with adjustable rebound and spring preload.

Wheels & Brakes

Front Tire Size120/70-17
Rear Tire Size180/55-17
Front Brakes2 x 320 mm , discs 4 piston caliper
Rear BrakesSingle 240 mm disc, 2 piston caliper

Dimension & Weights

Overall Length2183 mm / 85.9 in
Overall Width850 mm / 37.4 in
Overall Height1320 mm / 51.9 in
Seat Height31.9 inches / 810 mm
Wheelbase59.6 inches / 1515 mm
Ground Clearance140 mm / 5.7 in
Fuel Tank Capacity5.7 US gallons / 21.5 L
Dry Weight205 kg / 451.9 lbs

Features

  • Mixed steel tube front trellis frame
  • Aluminium alloy castings in boxed rear section
  • Aluminium die-cast subframe
  • ASD steel tube swingarm with Extreme Technology single shock absorber
  • Adjustable rebound and spring preload on shock absorber
  • Wet sump lubrication
  • Electronic injection
  • Double overhead camshaft
  • 4 valves per cylinder
  • Hydraulic command clutch
  • 6 speed gearbox
  • Front hydraulic 50 mm suspension
  • Rear adjustable hydraulic single shock absorber
  • Two 320 mm Brembo discs with 4 piston calipers on front wheel
  • One 240 mm disc and double piston caliper on rear wheel
  • 17 inch wheels
  • Wide-sectioned front tyres (120/70-ZR17)
  • Wide-sectioned rear tyres (180/55-ZR17, 190/50 optional)
  • Windshield for protection
  • Compact headlight fairing for rider and passenger protection
  • Well-visible dashboard
