The Benelli Tornado Tre 1130 is a testament to the brand’s commitment to innovation and performance. Its revised chassis boasts a mixed-solution front end, featuring an aluminium alloy castings subframe and asymmetric swingarm with Extreme Technology single shock absorber. This engineering marvel allows for 50% weight distribution to the front, delivering precise handling and agility when navigating bends.
The Tornado Tre’s three-cylinder engine is a powerhouse, producing 120 kW at 10,500 RPM and 124 Nm of torque. Fed through a fuel injection system, this robust engine complements the chassis’s abilities, providing a thrilling riding experience. By addressing the missing piston disadvantage with its 1130cc engine, Benelli has created a true competitor in the sporty bike market.
Incorporating lessons learned from racing, the Tornado Tre is a masterclass in design and engineering, offering an unparalleled blend of power, handling, and style that sets it apart from its peers.
Key Specifications
Engine Type
Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Engine Capacity
1130 cc / 69 cu in
Max Power
120 kw / 163 hp
Max Torque
124 Nm / 12.6 kgf-m / 91.45 lb-ft @ 8000 rpm
Fuel Tank Capacity
20.8 Litres / 5.5 gal
Seat Height
31.8 inches / 807 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Benelli Tornado Tre 1130
Year
2006 – 2007
Engine
Engine Type
Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Marzocchi upside down stanchion fork50mm, adjustable in compression and extension with spring pre-load
Rear Suspension
Asymmetric swingarm, composed of cast aluminium and pressed in aluminium alloy, with Extreme Technology single shock absorber adjustable in compression,dual regulation for low and high speed damping andextension and spring pre-load.
Wheels & Brakes
Front Tire Size
120/70-17
Rear Tire Size
190/50-17
Front Brakes
2 x 320mm discs, 4 piston caliper
Rear Brakes
Single 240 mm disc, 2 piston caliper
Dimension & Weights
Seat Height
31.8 inches / 807 mm
Wheelbase
55.9 inches / 1419 mm
Ground Clearance
140 mm / 5.7 in
Fuel Tank Capacity
20.8 Litres / 5.5 gal
Dry Weight
195 kg / 430 lbs
Features
50% weight distribution to front chassis for increased precision and handling.
Asymmetric swingarm composed of cast aluminum and pressed in aluminum alloy.
Extreme Technology single shock absorber adjustable in compression.
Dual regulation for low and high speed damping.
Spring pre-load adjustment.
Aluminium die-cast subframe.
Cast aluminium rear subframe.
Revised Tornados frame to meet new engine power and torque characteristics.
Improved welding system and tube assembly accuracy.
Modified aluminum plates for improved riding experience.
1130cc three-cylinder engine with fuel injection system.
Engine produces 120 kW at 10,500 RPM.
Engine produces 124 Nm at 8,000 RPM.
Aggressive styled motorcycle with distinctive front end.
Y-shaped screen and headlight design.
Air scoops on headlights’ sides for unique look.
Benelli nameplate prominently displayed on each side of the bike.
