Benelli TNT 1130 Sport (2005 – 2006)

Benelli TNT 1130 Sport (2005 - 2006)

The Benelli TNT 1130 Sport is a high-performance motorcycle designed for the most enthusiastic sports riders. Its four-stroke, transverse three-cylinder engine delivers exceptional power and torque, with a unique twist: the ability to switch between free power and controlled power modes via a simple button on the dashboard.

This innovative feature not only enhances rideability in various conditions but also reduces fuel consumption by 10-20% depending on driving style. The suspension setting has been meticulously fine-tuned for stability and manageability, featuring a Marzocchi fork with reversed rods and adjustable spring compression, extension, and preload.

The Brembo braking system takes center stage, equipped with double floating disks at the front and a 4-piston radial calliper, providing optimal response during braking. With its exceptional power-to-weight ratio and advanced technology, the Benelli TNT 1130 Sport is an exhilarating ride that demands to be pushed to the limit, guaranteeing unforgettable experiences on both road and track.

Key Specifications

Engine TypeFour stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Engine Capacity1130 cc / 69 cu in
Max Power96.9 kW kW / 130 hp @ 9500 rpm
Max Torque117 Nm / 11.9 kgf-m / 86.3 lb-ft @ 7750 rpm
Fuel Tank Capacity16.5 L / 4.4 US gal
Seat Height30.7 inches / 780 mm
Benelli TNT 1130 Sport (2005 - 2006)

All Specifications

Make & Model

ModelBenelli TNT 1130 Sport
Year2005 – 2006

Engine

Engine TypeFour stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Displacement1130 cc / 69 cu in
Bore x Stroke88 x 62 mm
Compression Ratio11.5:1
Max Horsepower96.9 kW kW / 130 hp @ 9500 rpm
Max Torque117 Nm / 11.9 kgf-m / 86.3 lb-ft @ 7750 rpm
Engine Management SystemElectronic injectionwith1injectorpercylinder
Lubrication SystemWet sump
Cooling SystemLiquid cooled
ExhaustWith catalytic converter and oxygen sensor

Performance

Top Speed253 km/h / 157 mph

Transmission

ClutchWet
Gearbox6 Speed
Gear Ratios1st 2.786 / 2nd 1.994 / 3rd 1.524 / 4th 1.304 / 5th 1.167 / 6th 0.926
Final DriveChain

Electrical & Electronics System

Battery12V, 10Ah
StarterElectric

Chassis & Suspension

Frame TypeFrontASDsteeltubetrellis,fastenedwithdrawerscrewstoboxedrearsection,aluminium alloycastings.
Front SuspensionMarzocchi50mmdiameterupsidedownforkASDsteeltubetrellisoscillatingmainfork
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionMonoshockabsorberwithadjustableextensionandspringload
Rear Suspension Travel4.5 inches / 115 mm
Rake25
Trail96 mm / 3.7 in

Wheels & Brakes

WheelsAluminium alloy, 10-spoke
Front Wheel/Rim Size3.5 x 17 in
Front Tire Size120/70-ZR17 (58W)
Rear Wheel/Rim Size6.0 x 17 in
Rear Tire Size190/55-ZR17 (73W)
Front Brakes2 x 320 mm discs, 4 piston calipers
Rear BrakesSingle 240 mm disc, 2 piston caliper

Dimension & Weights

Overall Length2100 mm / 82.7 in
Overall Width790 mm / 31.1 in
Seat Height30.7 inches / 780 mm
Wheelbase56.8 inches / 1443 mm
Fuel Tank Capacity16.5 L / 4.4 US gal
Dry Weight199 kg / 439 lbs

Features

  • Four stroke engine
  • Transverse three cylinder layout
  • DOHC engine design
  • 4 valves per cylinder
  • 6-speed transmission
  • Gear ratios: 1st 2.786, 2nd 1.994, 3rd 1.524, 4th 1.304, 5th 1.167, 6th 0.926
  • Front suspension: Marzocchi fork with ASD steel tube trellis and oscillating main fork
  • Rear suspension: Monoshock absorber with adjustable extension and spring load
  • Aluminium alloy castings for frame
  • New colours available
  • Exclusive components
  • Engine control unit with power mode selection (free power or controlled power)
  • Power mode selection via button on dash support
  • Fuel consumption reduction of 10-20% with controlled power configuration
  • Double floating disk, 320 mm, front brake with 4 piston radial calliper
  • Brembo braking system
