Benelli TNT 1130 Naked (2004)

The Benelli TNT 1130 Naked is a high-performance motorcycle that embodies the spirit of Italian design and engineering. Its four-stroke, transverse three-cylinder engine delivers a thrilling riding experience, with a unique blend of power and character.

With its DOHC configuration and 4 valves per cylinder, this engine produces a wide spread of torque across the rev range, making it perfect for both road and track use. The suspension settings have been carefully tuned to provide exceptional stability and manageability in all riding conditions.

The TNT 1130 Naked features a powerful Brembo braking system with double floating disks at the front, providing optimal stopping power and control. But what truly sets this motorcycle apart is its innovative engine control unit, which allows riders to switch between free power and controlled power modes with the simple press of a button.

This feature not only enhances safety in poor traction conditions but also reduces fuel consumption by up to 20%, making it an exciting proposition for thrill-seekers and commuters alike. The Benelli TNT 1130 Naked is a motorcycle that truly has something for everyone, offering a unique combination of performance, style, and practicality that’s sure to leave a lasting impression on any rider who dares to ride it.

Key Specifications

Engine Type	Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Engine Capacity	1130 cc / 69 cu in
Max Power	101 kw / 135 hp
Max Torque	110 Nm / 11.2 kgf-m / 81.1 lb-ft @ 7750 rpm
Fuel Tank Capacity	16.5 L / 4.4 US gal
Weight (Wet/Kerb)	474 lbs / 215 kg
Seat Height	30.7 inches / 780 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Benelli TNT 1130 Naked
Year	2004

Engine

Engine Type	Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Displacement	1130 cc / 69 cu in
Bore x Stroke	88 x 62 mm
Compression Ratio	11.5:1
Max Horsepower	101 kw / 135 hp
Max Torque	110 Nm / 11.2 kgf-m / 81.1 lb-ft @ 7750 rpm
Engine Management System	Electronic injectionwith1injectorpercylinder
Lubrication System	Wet sump
Cooling System	Liquid cooled

Performance

Top Speed

243 km/h / 151 mph

*n/a – information not provided by manufacturer

Transmission

Clutch	Oil bath
Gearbox	6 Speed
Gear Ratios	1st 2.786 / 2nd 1.994 / 3rd 1.524 / 4th 1.304 / 5th 1.167 / 6th 0.926
Final Drive	Chain

Electrical & Electronics System

Battery	12V, 10Ah
Starter	Electric

Chassis & Suspension

Frame Type	FrontASDsteeltubetrellis,fastenedwithdrawerscrewstoboxedrearsection,aluminium alloycastings.
Front Suspension	Marzocchi50mmdiameterupsidedownforkASDsteeltubetrellisoscillatingmainfork
Front Suspension Travel	4.7 inches / 120 mm
Rear Suspension	Monoshockabsorberwithadjustableextensionandspringload
Rear Suspension Travel	4.5 inches / 115 mm
Rake	23.5
Trail	100 mm / 3.9 in

Wheels & Brakes

Wheels	Aluminium alloy, 5-spoke
Front Wheel/Rim Size	3.5 x 17 in
Front Tire Size	120/70-ZR17 (58W)
Rear Wheel/Rim Size	6.0 x 17 in
Rear Tire Size	190/55-ZR17 (73W)
Front Brakes	2 x 320 mm discs, 4 piston calipers
Rear Brakes	Single 240 mm disc, 2 piston caliper

Dimension & Weights

Overall Length	2100 mm / 82.7 in
Overall Width	900 mm / 35.4 in
Overall Height	1050 mm / 41.3 in
Seat Height	30.7 inches / 780 mm
Wheelbase	56.8 inches / 1443 mm
Fuel Tank Capacity	16.5 L / 4.4 US gal
Wet (kerb/curb) Weight	474 lbs / 215 kg
Dry Weight	205 kg / 452 lbs

Features

Transverse three cylinder engine
DOHC design
4 valves per cylinder
6-speed transmission
Front ASD steel tube trellis frame
Boxed rear section with aluminium alloy castings
Marzocchi 50mm diameter upside down fork
Oscillating main fork
Monoshock absorber with adjustable extension and spring load
Brembo system with double floating disk, 320 mm at front
4 piston radial calliper at front
Engine control unit with free power and controlled power configuration
Ability to switch between free power and controlled power modes via dash support button
Potential fuel consumption decrease of 10-20% depending on driving style and road conditions
