The Benelli TNT 1130 K is a high-performance sports motorcycle that embodies the essence of raw power and unbridled excitement. Its in-line triple engine produces a maximum power output of 129 hp at 8500 rpm, accompanied by a substantial torque of 110 Nm at 5250 rpm.
With its distinctive fully adjustable fork, combined with a hydraulic spring preload on the rear absorber, this bike offers an unparalleled riding experience, allowing riders to adapt the suspension to their needs. The TNT 1130’s engine character is marked by a snappy throttle response and a thrilling mid-range punch, making it a joy to ride.
Whether navigating twisty roads or carving through corners, the Benelli TNT 1130 K delivers an exhilarating experience that will leave riders craving more.
Key Specifications
Engine Type
Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Engine Capacity
1131 cc / 69 in
Max Power
92 kw / 123 hp
Fuel Tank Capacity
4.2 US gallons / 16.0 L
Weight (Wet/Kerb)
474 lbs / 215 kg
Seat Height
33.5 inches / 849 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Benelli TNT 1130 K
Year
2015
Engine
Engine Type
Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder
Displacement
1131 cc / 69 in
Bore x Stroke
88 x 62 mm
Compression Ratio
11.6:1
Max Horsepower
92 kw / 123 hp
Engine Management System
Electronic injectionwith1injectorpercylinder
Lubrication System
Wet sump
Cooling System
Liquid cooled
Exhaust
With catalytic converter and oxygen sensor
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet clutch with hydraulic command
Gearbox
6 Speed
Final Drive
Chain drive, ratio 16:37
Electrical & Electronics System
Chassis & Suspension
Frame Type
Decomposable, front steel trestle, rear aluminium alloy casting
Front Suspension
50 mm upside-down fork, with hydraulic extension, compression and spring preload adjustments
Front Suspension Travel
5.9 inches / 150 mm
Rear Suspension
Steel tube trestle swingarm, rear dumper with hydraulic adjustment (extension, high and low speed compression) and spring preload assembled with progressive link
Rear Suspension Travel
5.7 inches / 144 mm
Wheels & Brakes
Front Tire Size
120/70-17
Rear Tire Size
190/50-17
Front Brakes
2 x 320 mm discs, 4 piston caliper
Rear Brakes
Single 240 mm disc, 2 piston caliper
Dimension & Weights
Overall Length
2182 mm / 85.9 in
Overall Width
849 mm / 33.5 in
Seat Height
33.5 inches / 849 mm
Wheelbase
59.7 inches / 1515 mm
Fuel Tank Capacity
4.2 US gallons / 16.0 L
Wet (kerb/curb) Weight
474 lbs / 215 kg
Dry Weight
205 kg / 452 lbs
Features
Front steel trestle design
Rear aluminium alloy casting swingarm
Hydraulic rear dumper with adjustable compression and extension
Spring preload adjustment
Progressive link A assembly
In-line triple cylinder engine
Maximum power of 129 hp at 8500 rpm
Maximum torque of 110 Nm at 5250 rpm
Fully adjustable fork
Hydraulic spring preload on rear suspension
ZF Sachs fully adjustable rear absorber
Carbon muffler available as accessory
Front and rear carbon mudguards available as accessories
Carbon belly pans available as accessories
Adjustable brake/clutch levers in ergal
