The 1977 Benelli 500LS embodies Italian style and performance, boasting a sleek design that exudes sophistication. Power comes from a 499cc four-stroke twin engine, delivering a smooth yet potent punch to the rider. This engine is known for its silky-smooth power delivery and distinctive sound, perfect for those who crave character in their ride.
The bike’s handling is equally impressive, with a robust steel frame that provides stability at high speeds. Suspension travel has been increased for added comfort on twisty roads, ensuring an enjoyable experience for both the rider and passenger.
A true classic for enthusiasts of raw Italian flair and unbridled performance, the 1977 Benelli 500LS is an unforgettable ride for those who crave adventure and excitement on two wheels.
Key Specifications
Engine Type
Four stroke, transverse four cylinders , 2 valves per cylinder
Engine Capacity
498 cc / 30.4 cu in
Max Power
36.5 kw / 49 hp
Max Torque
34 Nm / 3.47 kgf-m / 25.1 lbs-ft @ 9300 rpm
Fuel Tank Capacity
5.02 US gallons / 19.0 L
Weight (Wet/Kerb)
507 lbs / 230 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Benelli 500LS
Year
1977
Engine
Engine Type
Four stroke, transverse four cylinders , 2 valves per cylinder
Displacement
498 cc / 30.4 cu in
Bore x Stroke
56 x 50.6 mm
Compression Ratio
10.2:1
Max Horsepower
36.5 kw / 49 hp
Max Torque
34 Nm / 3.47 kgf-m / 25.1 lbs-ft @ 9300 rpm
Engine Management System
4 x 22mm Dell’Orto carburetors
Performance
Top Speed
180 km/h / 111 mph
Fuel Consumption
6.7 L/100 km / 14.9 km/l / 35.1 US mpg
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Electrical & Electronics System
Starter
Electric and kick start
Chassis & Suspension
Front Suspension
Telescopic forks
Rear Suspension
Pivoted rear fork 5-way spring preload
Wheels & Brakes
Front Tire Size
3.00-18
Rear Tire Size
3.50-18
Front Brakes
2 x 260mm discs
Rear Brakes
200 mm drum
Dimension & Weights
Overall Length
2100 mm / 82.7 in
Overall Width
800 mm / 31.5 in
Overall Height
1000 mm / 39.4 in
Fuel Tank Capacity
5.02 US gallons / 19.0 L
Wet (kerb/curb) Weight
507 lbs / 230 kg
Dry Weight
198 kg / 437 lbs
