The Benelli 500 Quattro: a behemoth of a bike that roared onto the scene in the mid-1970s. Its 499cc four-stroke engine, fed by a trio of Zenith carbs, belched out an impressive 40 horsepower and 30 lb-ft of torque, making it one of the most potent machines on two wheels.
Its V-twin configuration, with cylinders angled at 45 degrees, gave the Quattro its signature character – a throaty, raspy exhaust note that seemed to sing in perfect harmony with every gear change. And what a joy it was to ride: the Benelli’s long-travel suspension soothed even the most turbulent of roads, while its ample power ensured you were never short on pace.
The result is an unforgettable riding experience – one that combines raw power, agile handling and an unmistakable Italian flair.
Key Specifications
Engine Type
Four stroke, transverse four cylinders, 2 valves per cylinder, SOHC
Engine Capacity
498 cc / 30.4 cu in
Max Power
32.8 kw / 45 hp
Max Torque
34 Nm / 3.47 kgf-m / 25.1 lbs-ft @ 9300 rpm
Fuel Tank Capacity
5.02 US gallons / 19.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Benelli 500 Quattro
Year
1974 – 75
Engine
Engine Type
Four stroke, transverse four cylinders, 2 valves per cylinder, SOHC
Displacement
498 cc / 30.4 cu in
Bore x Stroke
56 x 50.6 mm
Compression Ratio
10.2:1
Max Horsepower
32.8 kw / 45 hp
Max Torque
34 Nm / 3.47 kgf-m / 25.1 lbs-ft @ 9300 rpm
Engine Management System
4 x 22mm Dell’Orto carbs
Cooling System
Air cooled
Performance
Top Speed
172 km/h / 107 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric and kickstart
Chassis & Suspension
Front Suspension
Telescopic forks
Rear Suspension
Pivoted rear fork 5-way spring preload
Wheels & Brakes
Front Tire Size
3.25-18
Rear Tire Size
4.10-18
Front Brakes
Drum
Rear Brakes
Drum
Dimension & Weights
Fuel Tank Capacity
5.02 US gallons / 19.0 L
Dry Weight
200 kg / 440 lbs
