Benelli 250 2C Phantom (1974 – 76)

Benelli 250 2C Phantom (1974 - 76)

The Benelli 250 2C Phantom is a unique gem in the Italian firm’s lineup, offering a distinct alternative to their more refined brethren. This two-stroke, twin-cylinder bike boasts a compact yet potent engine, displacing 231cc and extracting 30 bhp at 8000 rpm.

Its performance is remarkable, with a top speed of 90 mph and an impressive fuel economy of 45 mpg. The five-speed gearbox with left-foot change provides seamless shifting, while the duplex frame and conventional suspension ensure exceptional handling and roadholding.

Despite its many strengths, the Benelli 250 2C Phantom falls short in terms of finish and appearance, lacking the polish of Japanese manufacturers. Nonetheless, it remains a compelling choice for those seeking an authentic Italian motorcycle experience that will not be forgotten anytime soon.

Key Specifications

Engine TypeTwo stroke, parallel twin
Engine Capacity231.4 cc / 14.1 cu in
Max Power19 kw / 25 hp
Max Torque25.5 Nm / 2.6 kgf-m / 18.8 lb-ft @ 6500 rpm
Fuel Tank Capacity3.7 US gallons / 14.0 L
Benelli 250 2C Phantom (1974 - 76)

All Specifications

Make & Model

ModelBenelli 250 2C Phantom
Year1974 – 76

Engine

Engine TypeTwo stroke, parallel twin
Displacement231.4 cc / 14.1 cu in
Bore x Stroke56 x 47 mm
Compression Ratio10.0:1
Max Horsepower19 kw / 25 hp
Max Torque25.5 Nm / 2.6 kgf-m / 18.8 lb-ft @ 6500 rpm
Engine Management System2 x 26 mm Dell’Orto VHB carburetors
Lubrication SystemPetroil, 20:1 mixture
Cooling SystemAir cooled

Performance

Top Speed145 km/h / 90 mph

Transmission

ClutchWet, multidisc
Gearbox5 Speed
Gear Ratios1st 20.10 / 2nd 13.18 / 3rd 9.22 / 4th 7.41 / 5th 6.21:1
Final DriveChain

Electrical & Electronics System

StarterKick start

Chassis & Suspension

Frame TypeDouble cradle, tubular steel
Front SuspensionTelescopic forks
Rear SuspensionSwinging arm with double adjustable shocks and concentric springs

Wheels & Brakes

Front Tire Size3.00-18
Rear Tire Size3.25-18
Front BrakesDrum with 4 selfwinding shoes, 180 mm
Rear BrakesDrum, 158 mm

Dimension & Weights

Wheelbase51.6 inches / 1310 mm
Fuel Tank Capacity3.7 US gallons / 14.0 L
Dry Weight136.5 kg / 301 lbs

Features

  • 231cc two-stroke twin-cylinder engine
  • 56mm bore and 47mm stroke
  • 30 bhp at 8000 rpm
  • Five-speed gearbox with left-foot change
  • Duplex frame design
  • Conventional suspension
  • Taut and well-designed handling and roadholding
  • Petroil mixture fueling system (no self-mixing setup)
  • Drum brakes front and rear on standard model
  • Front disc brake available as an option
  • Disc brake not effective in wet conditions compared to drum brake
