The Aprilia Tuono V4 R APRC (2012) boasts an aluminum dual beam chassis that marries pressed and cast sheet elements for exceptional strength and agility. This potent package is further elevated by the inclusion of a Sachs steering damper, providing unparalleled efficacy and riding pleasure.
At its core lies the APRC second-generation vehicle dynamic control suite, which leverages an automotive inertia sensor platform to monitor the motorcycle’s dynamic state. This allows the engine ECU to dynamically adjust engine torque, empowering riders to unlock the full performance potential of the bike.
The APRC suite is comprised of four distinct functions: ATC (Aprilia Traction Control), AWC (Aprilia Wheelie Control), QS (Aprilia Quick Shift), and ALC (Aprilia Launch Control). The latter, in particular, is a showstopper – with 167.3 horsepower at its disposal, the Tuono V4 R can be unleashed like a missile as soon as the clutch is released. And with APRC’s Calibrating function capable of self-adapting to tyre size, this system stands alone on the market.
Key Specifications
Engine Type
Four stroke,longitudinal65 V four , DOHC, 4 valves per cylinder
Engine Capacity
60.9 cubic inches / 9 cc
Max Power
124.7 kw / 167.3 hp
Max Torque
111.5 Nm / 11.4 kgf-m 82.2 lb/ft @ 9500 rpm
Fuel Tank Capacity
17 Liters / 4.5 gal
Seat Height
32.8 inches / 833 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Aprilia Tuono V4 R APRC
Year
2012
Engine
Engine Type
Four stroke,longitudinal65 V four , DOHC, 4 valves per cylinder
Displacement
60.9 cubic inches / 9 cc
Bore x Stroke
78 x 52.3 mm
Compression Ratio
13.0:1
Max Horsepower
124.7 kw / 167.3 hp
Max Torque
111.5 Nm / 11.4 kgf-m 82.2 lb/ft @ 9500 rpm
Engine Management System
Airbox with front dynamic air intakes; 4 Weber-Marelli 48-mm throttle bodies with 4 injectors and latest generation Ride-by-Wire engine management.
Lubrication System
Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)
Cooling System
Liquid cooled
Exhaust
4 into 2 into 1 layout, single oxygen sensor, lateral single silencer with ECU-controlled bypass valve and integrated trivalent catalytic converter (Euro 3)
Bosch 9MP, adjustable on 3 maps, featuring RLM strategy and disconnectable.
Chassis & Suspension
Frame Type
Aluminum dual beam chassis with pressed and cast sheet elements. Steering Damper: Sachs
Front Suspension
Sachs upside-down one by one fork, stanchions 43 mm. Forged aluminum feet for radial calliper mounting; Completely adjustable spring preload and hydraulic compression and rebound damping;
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Double braced aluminum swingarm; mixed low thickness and sheet casting technology; Sachs piggy back monoshock with completely adjustable: spring preload and hydraulic compression and rebound damping. APS progressive linkage;
2 x 320 mm floating stainless steel discs with lightweight stainless steel rotor with 6 studs. Brembo monobloc radial callipers M432 with 4 horizontally opposed 32 mm pistons. Sintered pads. Axial pump master cylinder and metal braided brake hoses.
Rear Brakes
Single 220 mm diameter disc, Brembo floating calliper with two 32 mm isolated pistons. Sintered pads. Pump with integrated tank and metal braided hose.
ABS
Bosch 9MP, adjustable on 3 maps, featuring RLM strategy and disconnectable.
Dimension & Weights
Overall Length
2065 mm / 81.2 in
Overall Width
800 mm / 31.4 in (at the handlebar) Height : 1090 mm / 42.9 in
Seat Height
32.8 inches / 833 mm
Wheelbase
56.8 inches / 1435 mm
Ground Clearance
125 mm / 4.9 in
Fuel Tank Capacity
17 Liters / 4.5 gal
Dry Weight
183 kg / 403.4 lbs
Features
Aluminum dual beam chassis
Pressed and cast sheet elements
Sachs Steering Damper
APRC (vehicle dynamic control suite)
ATC (Aprilia Traction Control) with eight different settings
AWC (Aprilia Wheelie Control)
QS (Aprilia Quick Shift)
ALC (Aprilia Launch Control)
Self-adapting to tyre size and drive ratio through Calibrating function
Two distinct display modes – Road and Race
167.3 horsepower engine
190/55 rear tyre
