Aprilia SMV 750 Dorsoduro (2013)

Aprilia SMV 750 Dorsoduro (2013)

The Aprilia SMV 750 Dorsoduro is a masterclass in motorcycle engineering, distilling the collective experience of Aprilia Racing’s 37 world titles into a single, exhilarating package. This supermotard boasts a potent new-generation engine, delivering an astonishing 92 horsepower and 82 Nm of torque at just 4,500 rpm.

The Dorsoduro’s chassis is a marvel of design, combining trellis and aluminum components to deliver unparalleled directional control, responsiveness, and precision. And with advanced electronic engine management, this bike is capable of elevating even the most expert riders to new heights of motorcycling excellence.

Whether carving through twisties or devouring open roads, the Dorsoduro 750 promises an unforgettable riding experience. Its exclusive Tri-Map ride-by-wire technology and four-piston radial calipers ensure precise control and unparalleled performance.

Key Specifications

Engine TypeFour stroke, longitudinal 90V twin, DOHC, 4 valves per cylinder
Engine Capacity45.7 cubic inches / 749.9 cc
Max Power67.3 kw / 92 hp
Max Torque82 Nm / 8.36 kgf-m / 60.4 lb/ft / @ 4500 rpm
Fuel Tank Capacity3.17 US gallons / 12.0 L
Aprilia SMV 750 Dorsoduro (2013)

All Specifications

Make & Model

ModelAprilia SMV 750 Dorsoduro
Year2013

Engine

Engine TypeFour stroke, longitudinal 90V twin, DOHC, 4 valves per cylinder
Displacement45.7 cubic inches / 749.9 cc
Bore x Stroke92 x 56.4 mm
Compression Ratio11.0:1
Max Horsepower67.3 kw / 92 hp
Max Torque82 Nm / 8.36 kgf-m / 60.4 lb/ft / @ 4500 rpm
Engine Management SystemIntegrated engine management system. Latest generation 3 maps (Sport, Touring, Rain) Ride-by-Wire throttle management.
Lubrication SystemWet sump
Cooling SystemLiquid cooled
Exhaust2 into 1 exhaust system in 100% stainless steel with three-way catalytic converter and lambda probe

Performance

Top Speed202.9 km/h / 126 mph

Transmission

ClutchMultiplate wet clutch, hydraulically operated
Gearbox6 Speed
Gear Ratios1st 36:14 (2.57) / 2nd 32:17 (1.88) / 3rd 30:20 (1.5) / 4th 28:22 (1.27) / 5th 23:/26 (0.88) / 6th 24:25 (0.96)
Final DriveChain

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeModular steal trellis secured to albumin side plates by high steal bolts.
Front Suspension43 mm Upside-down fork.
Front Suspension Travel6.5 inches / 167 mm
Rear SuspensionAluminium alloy swingarm with reinforcement truss. Hydraulic shock absorber adjustable in spring preload and rebound damping.
Rear Suspension Travel5.9 inches / 150 mm

Wheels & Brakes

WheelsAluminium alloy
Front Wheel/Rim Size3.5 x 17
Front Tire Size120/70ZR17
Rear Wheel/Rim Size6.00 x 17
Rear Tire Size190/55ZR17
Front Brakes2 x 320 mm discs, 4 piston caliper
Rear BrakesSingle 240 mm disc, 1 piston caliper

Dimension & Weights

Fuel Tank Capacity3.17 US gallons / 12.0 L
Dry Weight186 kg / 409 lbs

Features

  • 90 V twin engine with four-valve heads, double overhead cam and liquid cooling
  • Tri-Map second generation ride-by-wire technology
  • Electronic fuel injection with the latest generation injectors
  • Mixed gear and chain timing drive
  • Modular steel trellis and aluminium alloy frame for extremely light weight and high torsional rigidity
  • Aluminium alloy swingarm with laterally offset monoshock
  • Fully adjustable 43 mm upside down fork
  • Radial front brake calipers combined with 320 mm wave discs
  • Latest generation Continental two channel ABS
  • Adjustable front and rear suspension
  • Hydraulic wet clutch
  • Wave discs
  • Four piston radial calipers
  • Matrix instrument display with on-board computer
  • Restricted 25 kW version available
