The Aprilia RX 125R is a potent blend of Italian engineering and high-performance design. Its single-cylinder, two-stroke engine packs a punch, thanks in part to the Rotax 123 powerplant and the innovative Gilardoni 2 cylinder/head setup. This potent combination delivers a thrilling riding experience, with instant throttle response and a willingness to rev that’s hard to resist.
Riding the RX 125R is an exercise in finesse, as the bike’s agility and handling make it equally at home on twisty roads or tight urban environments.
The result is an exhilarating ride that puts riders firmly in control – the Aprilia RX 125R is a true thrill-seeker’s delight.
Key Specifications
Engine Type
Single cylinder, two stroke, Rotax 123, Gilardoni 2 cylinder/head
Engine Capacity
124.8 cc / 7.6 cu in
Max Power
25.7 kw / 34.5 hp
Max Torque
21.6 Nm / 2.2 kgf-m / 15.9 lb-ft @ 10500 rpm
Fuel Tank Capacity
11.5 L / 3.0 US gal / 2.5 Imp gal
Weight (Wet/Kerb)
269 lbs / 122 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Aprilia RX 125R
Year
1992 – 93
Engine
Engine Type
Single cylinder, two stroke, Rotax 123, Gilardoni 2 cylinder/head
Displacement
124.8 cc / 7.6 cu in
Bore x Stroke
54 x 54.5 mm
Compression Ratio
12.5:1
Max Horsepower
25.7 kw / 34.5 hp
Max Torque
21.6 Nm / 2.2 kgf-m / 15.9 lb-ft @ 10500 rpm
Engine Management System
VHSB34 LD carburetor
Performance
Top Speed
132.2 km/h / 82.1 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
#520 Chain, 12T to 17T pinion gear, 49T spur gear
Electrical & Electronics System
Starter
Electric and kick
Chassis & Suspension
Front Suspension
Marzocchi upside down fork
Rear Suspension
Swingarm with single shock absorber, Aprilia Progressive System with fully adjustable Boge Sachs shock absorber
Wheels & Brakes
Front Tire Size
90/90-21
Rear Tire Size
120/90-18
Front Brakes
Single 250 mm disc
Rear Brakes
Single 220mm disc
Dimension & Weights
Fuel Tank Capacity
11.5 L / 3.0 US gal / 2.5 Imp gal
Wet (kerb/curb) Weight
269 lbs / 122 kg
Dry Weight
105 kg / 231 lbs
Features
Single cylinder engine
Two-stroke engine design
Rotax 123 engine model
Gilardoni 2-cylinder head
