The Aprilia RSV-4 RR Misano Limited Edition is a testament to the brand’s rich racing heritage, featuring a striking livery inspired by its earliest championship successes. At the heart of this exceptional motorcycle lies a 1103cc V4 engine, delivering unparalleled performance with its Ride-By-Wire technology and three customizable engine maps: Track, Sport, and Race.
The RSV-4 RR Misano Limited Edition boasts cutting-edge suspension components, including a Smart EC 2.0 electronically managed Öhlins NIX fork and Sachs monoshock, providing exceptional handling and stability on the track.
This limited edition model is a celebration of Aprilia’s racing legacy, with only 100 individually numbered units available for the US market. Each bike features a carbon fiber rear subframe, further emphasizing its commitment to performance and style.
For the lucky few who will get behind the handlebars of this exceptional machine, the experience promises to be nothing short of exhilarating, as they tap into the raw power and precision that has earned Aprilia three rider championships and four manufacturer titles in World Superbike competition.
Key Specifications
Engine Type
Four stroke,longitudinal65 V four , DOHC, 4 valves per cylinder
Engine Capacity
61.0 cubic inches / 999.6 cc
Max Power
148 kw / 201 hp
Max Torque
115 Nm / 11.9 kgf-m / 86.2 lb-ft @ 10500 rpm
Fuel Tank Capacity
4.9 US gallons / 18.5 L
Weight (Wet/Kerb)
450 lbs / 204 kg
Seat Height
33.5 inches / 853 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Aprilia RSV-4 RR Misano Limited Edition
Year
2020
Engine
Engine Type
Four stroke,longitudinal65 V four , DOHC, 4 valves per cylinder
Displacement
61.0 cubic inches / 999.6 cc
Bore x Stroke
78 x 52.3 mm
Compression Ratio
13.6:1
Max Horsepower
148 kw / 201 hp
Max Torque
115 Nm / 11.9 kgf-m / 86.2 lb-ft @ 10500 rpm
Engine Management System
Airboxwith front dynamic air intakes. 4 Marelli 48-mm throttle bodies with 8 injectors and latest generation Ride-By-Wire engine management. Choice of three different engine maps selectable by the rider with bike in motion: Track, Sport, Race
Lubrication System
Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)
Cooling System
Liquid cooled
Exhaust
4 into 2 into 1 layout, two lambda probes, lateral single silencer with ECU-controlled bypass valve and integrated trivalent catalytic converter
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Multi-disc oil bath with mechanical slipper system
Aluminium dual beam chassis with pressed and cast sheet elements Available adjustments: headstock position and rake; engine height; swingarm pin height. Smart EC 2.0 electronically managed hlins steering damper [Sachs steering damper]
Front Suspension
Smart EC 2.0 electronically managed hlins NIX fork. 43 mm stanchions, with TIN surface treatment. [Sachs fork with 43 mm stanchions]; Aluminium radial calliper mounting bracket. Adjustable spring pre-load and hydraulic compression and rebound damping.
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Sachs monoshock adjustable in: hydraulic compression and rebound damping, spring pre-load and centre-to-centre distance.
Rear Suspension Travel
5.1 inches / 130 mm
Trail
103 mm / 4.0 in
Wheels & Brakes
Wheels
Aprilia in aluminium alloy wheels with 3 split spoke design
2 x330mm diameter floating stainless steel disc with lightweight stainless steel rotor and aluminium flange with 6 pins. Brembo Stylema [M50] monobloc radial callipers with 4 30 mm opposing pistons. Sintered pads. Radial pump and metal braided brake hose
Rear Brakes
Single220mm diameter disc; Brembo calliper with two 32 mm separate pistons. Sintered pads. Pump with integrated tank and metal braided hose, Bosch 9.1 MP ABS with cornering function, adjustable to 3 maps equipped with RLM (Rear wheel Lift-up Mitigation) (can be disabled).
Dimension & Weights
Overall Length
2055 mm / 80.9 in
Overall Width
735 mm / 28.9 in (at the handlebar)
Seat Height
33.5 inches / 853 mm
Wheelbase
56.7 inches / 1441.6 mm
Ground Clearance
130 mm / 5.1 in
Fuel Tank Capacity
4.9 US gallons / 18.5 L
Wet (kerb/curb) Weight
450 lbs / 204 kg
Dry Weight
182 kg / 401 lbs
Features
Airbox with front dynamic air intakes
4 Marelli 48-mm throttle bodies with 8 injectors
Latest generation Ride-By-Wire engine management
Choice of three different engine maps: Track, Sport, Race
Magneti Marelli digital electronic ignition system
Adjustable spring pre-load and hydraulic compression and rebound damping on fork
Sachs monoshock with adjustable hydraulic compression and rebound damping, spring pre-load, and centre-to-centre distance
Carbon fiber front fenders (standard equipment)
Lithium batteries (standard equipment)
