The Aprilia RSV-4 Factory (2019) embodies the pinnacle of high-performance motorcycle engineering, boasting an extraordinary 217 HP V4 engine that redefines the boundaries of speed and agility. The Ride-By-Wire system delivers razor-sharp throttle response, while the three-mode engine map selection allows riders to tailor their experience on the go.
The airbox’s innovative dynamic air intakes and Marelli 48-mm throttle bodies with eight injectors further enhance the RSV-4’s exceptional performance capabilities. Meanwhile, the Smart EC 2.0 electronically managed suspension system ensures razor-sharp handling and precision.
With its lightweight construction, premium components, and state-of-the-art Bosch ABS with cornering function, this exceptional machine offers an unparalleled riding experience that few other motorcycles can match. And yet, despite all these incredible features, the Aprilia RSV-4 Factory (2019) remains a true extension of the rider’s will, responding intuitively to every command and delivering pure exhilaration on demand.
Key Specifications
Engine Type
Four stroke,longitudinal65 V four , DOHC, 4 valves per cylinder
Engine Capacity
85.7 cubic inches / 1077 cc
Max Power
217 hp / 159.6 kW @ 13200 rpm
Max Torque
90 ft-lb / 122 nm
Fuel Tank Capacity
4.9 US gallons / 18.5 L
Weight (Wet/Kerb)
450 lbs / 204 kg
Seat Height
33.5 inches / 853 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Aprilia RSV-4 Factory
Year
2019
Engine
Engine Type
Four stroke,longitudinal65 V four , DOHC, 4 valves per cylinder
Displacement
85.7 cubic inches / 1077 cc
Bore x Stroke
81 x 52.3 mm
Compression Ratio
13.6:1
Max Horsepower
217 hp / 159.6 kW @ 13200 rpm
Max Torque
90 ft-lb / 122 nm
Engine Management System
Airbox with front dynamic air intakes. 4 Marelli 48-mm throttle bodies with 8 injectors and latest generation Ride-By-Wire engine management. Choice of three different engine maps selectable by the rider with bike in motion: Track, Sport, Race
Lubrication System
Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)
Cooling System
Liquid cooled
Exhaust
4 into 2 into 1 layout, two lambda probes, lateral single silencer with ECU-controlled bypass valve and integrated trivalent catalytic converter
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Multi-disc oil bath with mechanical slipper system
Gearbox
6 Speed gearbox cassette type
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Aluminium dual beam chassis with pressed and cast sheet elements Available adjustments: headstock position and rake; engine height; swingarm pin height. Smart EC 2.0 electronically managed hlins steering damper
Front Suspension
Smart EC 2.0 electronically managed hlins NIX fork. 43 mm stanchions, with TIN surface treatment. [Sachs fork with 43 mm stanchions]; Aluminium radial calliper mounting bracket. Adjustable spring pre-load and hydraulic compression and rebound damping.
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Double braced aluminium swingarm; mixed low thickness and sheet casting technology. hlins TTX monoshock with Smart EC 2.0 electronically managed piggy-back, fully adjustable in: spring pre-load, wheelbase and hydraulic compression and rebound damping.
Rear Suspension Travel
5.1 inches / 130 mm
Trail
103 mm / 4.0 in
Wheels & Brakes
Wheels
Aprilia in aluminium alloy wheels with 3 split spoke design
2 x 330-mm diameter floating stainless steel disc with lightweight stainless steel rotor and aluminium flange with 6 pins. Brembo Stylema [M50] monobloc radial callipers with 4 30 mm opposing pistons. Sintered pads. Radial pump and metal braided brake hose
Rear Brakes
Single220 mm diameter disc; Brembo calliper with two 32 mm separate pistons. Sintered pads. Pump with integrated tank and metal braided hose Bosch 9.1 MP ABS with cornering function, adjustable to 3 maps equipped with RLM (Rear wheel Lift-up Mitigation) (can be disabled).
Dimension & Weights
Overall Length
2055 mm / 80.9 in
Overall Width
735 mm / 28.9 in (at the handlebar)
Seat Height
33.5 inches / 853 mm
Wheelbase
56.7 inches / 1441.6 mm
Ground Clearance
130 mm / 5.1 in
Fuel Tank Capacity
4.9 US gallons / 18.5 L
Wet (kerb/curb) Weight
450 lbs / 204 kg
Dry Weight
182 kg / 401 lbs
Features
Airbox with front dynamic air intakes
4 Marelli 48-mm throttle bodies with 8 injectors
Ride-By-Wire engine management
Three engine maps selectable by the rider: Track, Sport, Race
Magneti Marelli digital electronic ignition system
One spark plug per cylinder and stick-coil-type coils
