The 2009 Aprilia RSV-4 Factory is a game-changing machine that redefines the boundaries of performance and innovation. Powered by Aprilia’s all-new, 65-degree V4 engine, this potent package unleashes an estimated 180bhp in street trim, while the racing version pumps out an astonishing 210-220bhp.
The heart of this exceptional motorcycle is its advanced electronics system, featuring ride-by-wire throttle, three distinct fuel-injection maps, and electronic traction control. Paired with a lightweight aluminium twin-spar chassis, fully adjustable Öhlins suspension, and a unique swingarm design, the RSV-4 Factory offers an unparalleled riding experience.
This revolutionary machine is the culmination of Aprilia’s rich sporting heritage, which includes 31 world championships, 250 MotoGP wins, and 8 Superbike victories in the last sixteen years. With its cutting-edge design and technology, the RSV-4 Factory is poised to dominate the competition, cementing Aprilia’s reputation as a leader in the world of motorcycling.
The result is an extraordinary machine that embodies the perfect blend of power, handling, and electronics, making the Aprilia RSV-4 Factory the ultimate performance motorcycle.
Key Specifications
Engine Type
Four stroke,longitudinal65 V four , DOHC, 4 valves per cylinder
Engine Capacity
998.9 cc / 61 cu in
Max Power
132 kw / 180 hp
Max Torque
115 Nm / 11.7 kgf-m / 84.8 lb-ft @ 10000 rpm
Weight (Wet/Kerb)
453 lbs / 205 kg
Seat Height
33.3 inches / 845 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Aprilia RSV-4 Factory
Year
2009
Engine
Engine Type
Four stroke,longitudinal65 V four , DOHC, 4 valves per cylinder
Displacement
998.9 cc / 61 cu in
Bore x Stroke
78 x 52.3 mm
Compression Ratio
12.8:1
Max Horsepower
132 kw / 180 hp
Max Torque
115 Nm / 11.7 kgf-m / 84.8 lb-ft @ 10000 rpm
Engine Management System
Variable height intake trumpets. Airbox with aerodynamic side intakes. 4 Throttle bodes, 8 injectors, ride-by-wire fuel management. Multi-mapping
Lubrication System
Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)
Cooling System
Liquid cooled
Exhaust
4 into 2 into 1. Lambda probe oxygen sensor. Single lateral silencer. Integrated exhaust valve and catalytic converter. (Euro 3.)
Twin beam aluminium frame with mixed cast and pressed sheet sections. Adjustments for headstock position and angle, engine height, swingarm pivot height.
Front Suspension
hlins 43 mm upside-down fork. Lower fork bottoms for radial calipers. Adjustment for preload, compression and rebound.
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Double arch aluminium swingarm; mixed thin-wall casting and pressed sheet construction. hlins monoshock with piggy-back cylinder. Adjustments for compression, rebound, spring preload and length. APS rising rate linkages.
Rear Suspension Travel
5.1 inches / 130 mm
Trail
105 mm / 4.1 in
Wheels & Brakes
Front Tire Size
120/70 ZR17
Rear Tire Size
190/55 ZR17
Front Brakes
2 x 320 mm lightweight stainless steel floating discs, Brembo monobloc radial calipers with 4 opposed pistons. Sintered pads. Radial master cylinder. Metal braided brake line.
Rear Brakes
Single 220 mm disc. Brembo floating caliper with 2 insulated pistons. Sintered pads. Master cylinder with integral reservoir. Metal braided brake line.
Dimension & Weights
Overall Length
2040 mm / 80.3 in
Overall Width
735 mm / 28.9 in (at the handlebar)
Overall Height
1120 mm / 44.1 in
Seat Height
33.3 inches / 845 mm
Ground Clearance
130 mm / 5.1 in
Wet (kerb/curb) Weight
453 lbs / 205 kg
Dry Weight
179 Kg/ 395 lbs
Features
65-degree V4 engine
180bhp in street trim
190kg dry weight
Adjustable engine mounts
Aluminium swingarm
Fully adjustable Hlins suspension
Ride-by-wire throttle
Three different fuel-injection maps
Variable-length inlet tracts
Electronic traction control (standard on racing version)
Multi-mapping ride-by-wire technology
Prestigious materials used in engine construction
Advanced electronic management solutions
Compact and light chassis design
