AJP raised the bar in the enduro-leisure category to new heights with our SPR240… then we completely broke the bar with SPR240 Extreme! Basically a standard SPR240 on steroids, the SPR240X is the ultimate play bike and trail machine.
Key Specifications
Engine Type
Single Cylinder, 4 strokes, SOHC, 2 Valves
Engine Capacity
233 cc / 14.2 cubic inches
Fuel Tank Capacity
9.4 L / 2.5 US gal
Seat Height
919 mm / 36.2 inches
All Specifications
Make & Model
Model
AJP SPR 240X – ENDURO LEISURE
Year
2023
Engine
Engine
Single Cylinder, 4 strokes, SOHC, 2 Valves
Capacity
233 cc / 14.2 cubic inches
Bore x Stroke
69 x 62.2 mm
Cooling System
Air and Oil Cooled
Clutch
Oil bath, multi disc
Starting
Electric
Fuel System
Carburettor 30mm
Exhaust
1-in-1
Transmission
Transmission
5 Speed
Final Drive
Chain
Chassis & Suspension
Frame
Aluminium steel composite
Front Suspension
ZF Sachs USD 48 mm. Double closed cartridge fork
Front Suspension Travel
300 mm
Rear Suspension
ZF Sachs – Progressive system w/ reservoir
Rear Suspension Travel
300 mm
Wheels & Brakes
Wheels
Steel with wire spokes
Front Tyre
90/90 – 21
Rear Tyre
120/90 – 18
Front Brakes
Brembo 260 mm, double piston calliper
Rear Brakes
Brembo 220 mm, single piston calliper
Dimension & Weights
Wheelbase
1450 mm / 57.1 inches
Seat Height
919 mm / 36.2 inches
Ground Clearance
355.6 mm / 14 inches
Fuel Capacity
9.4 L / 2.5 US gal
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
