AJP PR5 250 AC SuperMoto, Enduro (2010 – 2012)

The AJP PR5 250 is a 249cc, four-stroke, single-cylinder, liquid-cooled motorcycle, commonly found in the off-road or enduro market. It’s known for its suspension, featuring race-grade components like a Marzocchi upside-down fork and a ZF Sachs monoshock. The PR5 250 is part of the AJP PR series, which is often compared to the Honda XR series.

Key Specifications

Engine Type	Single Cylinder, 4 strokes, SOHC, 4 Valves
Engine Capacity	249cc / 15.1 cubic inches
Power	18.4 KW / 24.6 hp @ 8500 r.p.m.
Torque	17 Nm @ 7000 r.p.m.
Fuel Tank Capacity	7.5 L
Weight (Wet/Kerb)	115 kg / 253.5 lbs
Seat Height	940mm

All Specifications

Make & Model

Model	AJP PR5 250 AC SuperMoto, Enduro
Year	2010 – 2012

Engine

Engine	Single Cylinder, 4 strokes, SOHC, 4 Valves
Capacity	249cc / 15.1 cubic inches
Bore x Stroke	73 x 59.5 mm
Cooling System	Air + Oil Cooled
Engine Oil	SAE 15W-40 API –SE, SF or SG
Engine Oil Capacity	1.4 L
Carburettor	Delphi Electronic Fuel Injection 34 mm
Battery	YTZ7S (12V 6Ah)
Spark Plug	LG D8TC (Champion A8YC or NGK DR8ES)
Starting	Electric
Exhaust	1-in-1
Max Power	18.4 KW / 24.6 hp @ 8500 r.p.m.
Max Torque	17 Nm @ 7000 r.p.m.

Transmission

Transmission	6 Speed
Final Drive	Chain

Chassis & Suspension

Frame	Aluminium double beam + steel double cradle
Front Suspension	ZF Sachs USD 48 mm
Front Suspension Travel	300 mm
Rear Suspension	ZF Sachs – Progressive system
Rear Suspension Travel	300 mm

Wheels & Brakes

Wheels	Steel with wire spokes
Front Tyre	SuperMoto – 100/80 – 17 Enduro – 90/90 – 21
Rear Tyre	SuperMoto – 130/70 – 17 Enduro – 120/80 – 18
Front Brakes	Disc 260 mm, double piston calliper
Rear Brakes	Disc 220 mm, double piston calliper

Dimension & Weights

Wheelbase	1460 mm / 57.4 inches
Seat Height	940 mm / 37 inches
Wet (kerb) Weight	115 kg / 253.5 lbs
Fuel Capacity	7.5 L
