Gas Gas EC 300 (2017)

Gas Gas EC 300 (2017)

The 2017 GasGas EC 300 is an uncompromising off-road machine, boasting a rich blend of performance and handling prowess.

At its core lies the Marzocchi Shiver fork, a fully adjustable closed-cartridge unit that soaks up rough terrain with ease. Paired with a German-made Reiger shock, this suspension duo delivers outstanding stability and poise.

The heart of the EC 300 is its potent 300cc two-stroke engine, renowned for its exceptional tractability down low and impressive mid-range pull. This remarkable power unit shines through in technical terrain, providing incredible traction and confidence-inspiring control.

Riding the EC 300 R is an exhilarating experience, with its well-balanced chassis and intuitive handling making it a joy to carve through challenging trails. With its E-start system, digital meter, and array of practical features, this middleweight off-roader is an absolute must-see for those seeking a worthy rival to the likes of KTM, Husqvarna, and Beta.

Key Specifications

Engine TypeTwo stroke, single cylinder,Direct reed valve VForce 4
Engine Capacity17.9 cubic inches / 294 cc
Max Power50 hp / 37.2 kW @ 7340 rpm
Max Torque26.1 ft-lb / 49 nm
Fuel Tank Capacity2.5 US gallons / 9.5 L
Seat Height37.4 inches / 950 mm
Gas Gas EC 300 (2017)

All Specifications

Make & Model

ModelGas Gas EC 300
Year2017

Engine

Engine TypeTwo stroke, single cylinder,Direct reed valve VForce 4
Displacement17.9 cubic inches / 294 cc
Bore x Stroke72 x 72 mm
Max Horsepower50 hp / 37.2 kW @ 7340 rpm
Max Torque26.1 ft-lb / 49 nm
Engine Management System38mm Keihin PWK carburetor
Lubrication System2-stroke-oil/fuel mixed 1:50
Cooling SystemLiquid cooled
ExhaustFMF Powercore 2

Performance

Top Speedn/a

Transmission

ClutchWet Multi-disc, hydraulic
Gearbox6 Speed
Final DriveChain

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeChromoly-steel, perimeter
Front SuspensionMarzocchi Shiver 48mm, closed cartridge, fully adjustable
Front Suspension Travel12 inches / 306 mm
Rear SuspensionReiger single shock, fully adjustable
Rear Suspension Travel11.7 inches / 298 mm

Wheels & Brakes

Front Tire Size90/90 -21
Rear Tire Size140/80 -18
Front BrakesSingle 260mmwavedisc 1 piston caliper
Rear BrakesSingle 220mm disc 1 piston caliper

Dimension & Weights

Seat Height37.4 inches / 950 mm
Wheelbase58.3 inches / 1480 mm
Ground Clearance340 mm / 13.4 in
Fuel Tank Capacity2.5 US gallons / 9.5 L
Dry Weight107.0 kg / 235.9 lbs

Features

  • Marzocchi Shiver 48mm, closed cartridge, fully adjustable fork
  • Adjustable power-valve
  • FMF muffler
  • Nissin brakes with Galfer Wave rotors
  • Excel rims
  • Metzeler Six Days Extreme tires
  • E-start with manual kick for backup
  • Digital meter
  • Headlight
  • Sidestand
  • Skid plate
  • Handguards
  • Reiger shock
  • Marzocchi closed-cartridge fork with updated internal valving
