Ducati 900 SS (1977)

Ducati900 SS (1977)

The Ducati 900 SS (1977) is a motorcycle that embodies the essence of Italian engineering and design. Its four-stroke, 90L twin-cylinder engine is a marvel of simplicity and elegance, boasting a SOHC configuration with two valves per cylinder.

As you fire up the Ducati 900 SS, its engine springs to life, delivering a unique blend of torque and power that is quintessentially Italian. The bevel gear driven camshafts add to the bike’s character, imbuing it with a sense of raw, unbridled energy.

Riding the Ducati 900 SS is an experience unlike any other, with its responsive handling and agile chassis making it a joy to carve through twisty roads and mountain passes.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, 2 valves per cylinder, bevel gear driven
Engine Capacity864 cc / 52.7 cu in
Max Power49.2 kw / 67 hp
Fuel Tank Capacity20 L / 5.3 US gal / 4.4 Imp gal
Seat Height29.9 inches / 760 mm
Ducati900 SS (1977)

All Specifications

Make & Model

ModelDucati900 SS
Year1977

Engine

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, 2 valves per cylinder, bevel gear driven
Displacement864 cc / 52.7 cu in
Bore x Stroke86 x 74.4 mm
Compression Ratio9.5:1
Max Horsepower49.2 kw / 67 hp
Engine Management System2 x Dell’Orto PHM 40 A, B or C carburetors
Cooling SystemAir cooled

Performance

Top Speed217 km/h / 135mph

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.187:1 (32/70)
Gear Ratios1st 2.237 / 2nd 1.562 / 3rd 1.203 / 4th 1.000 / 5th 0.887
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12N/12A-4A-12V
StarterKick (electric as an option)

Chassis & Suspension

Front Suspension38 mm Marzocchi fork
Rear SuspensionMarzocchi 310 mm dual shocks, 3-way adjustable

Wheels & Brakes

Front Wheel/Rim Size3.50 – 18
Rear Wheel/Rim Size4.00 – 18
Front Brakes2 x 280mm Disc, 1 piston caliper
Rear BrakesSingle 229 mm disc

Dimension & Weights

Overall Length2200 mm / 86.6 in
Overall Width675 mm / 26.6 in
Overall Height1050 mm / 41.3 in
Seat Height29.9 inches / 760 mm
Wheelbase59.0 inches / 1500 mm
Fuel Tank Capacity20 L / 5.3 US gal / 4.4 Imp gal
Dry Weight188 kg / 414 lbs

Features

  • Here is the extracted list:
  • Four stroke engine
  • 90L twin cylinder engine
  • Single overhead camshaft (SOHC)
  • 2 valves per cylinder
  • Bevel gear drive
