Ducati 900 SS (1975)

Ducati900 SS (1975)

The Ducati 900 SS: a road-legal production racer that embodied the raw, uncompromising spirit of its Imola 200 victory in 1972. This stunning V-twin superbike was born from the factory’s celebration of Paul Smart and Bruno Spaggiari’s historic win.

Its 864cc Desmo valve engine, featuring an impressive 79bhp at 7000rpm, delivered a rush of power that matched its razor-sharp handling. With clip-on handlebars, rear seat footrests, and twin Brembo front discs, the 900SS was a masterclass in minimalist design.

On the road, it was a visceral experience: a top speed of 135mph and a cruising speed of 100mph made it a thrilling companion for any rider. And when you wanted to really push its limits, the Ducati 900 SS revealed itself as a true track monster. With its raw, untamed character, this bike left an indelible mark on motorcycle history, cementing its place as one of the most iconic superbikes ever built.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, 2 valves per cylinder, bevel gear driven
Engine Capacity864 cc / 52.7 cu in
Max Power58.8 kw / 80 hp
Fuel Tank Capacity20 L / 5.3 US gal / 4.4 Imp gal
Seat Height29.9 inches / 760 mm
Ducati900 SS (1975)

All Specifications

Make & Model

ModelDucati900 SS
Year1975

Engine

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, 2 valves per cylinder, bevel gear driven
Displacement864 cc / 52.7 cu in
Bore x Stroke86 x 74.4 mm
Compression Ratio9.5:1
Max Horsepower58.8 kw / 80 hp
Engine Management System2 x Dell’Orto PHM 40 A, B or C carburetors
Cooling SystemAir cooled

Performance

Top Speed217 km/h / 135mph

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.187:1 (32/70)
Gear Ratios1st 2.237 / 2nd 1.562 / 3rd 1.203 / 4th 1.000 / 5th 0.887
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12N/12A-4A-12V
StarterKick (electric as an option)

Chassis & Suspension

Front Suspension38 mm Marzocchi fork
Rear SuspensionMarzocchi 310 mm dual shocks, 3-way adjustable

Wheels & Brakes

Front Wheel/Rim Size3.50 – 18
Rear Wheel/Rim Size4.00 – 18
Front Brakes2 x 280mm Disc, 1 piston caliper
Rear BrakesSingle 229 mm disc

Dimension & Weights

Overall Length2200 mm / 86.6 in
Overall Width675 mm / 26.6 in
Overall Height1050 mm / 41.3 in
Seat Height29.9 inches / 760 mm
Wheelbase59.0 inches / 1500 mm
Fuel Tank Capacity20 L / 5.3 US gal / 4.4 Imp gal
Dry Weight188 kg / 414 lbs

Features

  • Four-stroke engine
  • 90L twin cylinder engine
  • SOHC design
  • 2 valves per cylinder
  • Bevel gear driven
  • Original 900 Super Sport model was a production racer
  • Half-fairing design
  • Clip-on handlebars
  • Rear seat footrests
  • Twin drilled Brembo front discs
  • Single seat
  • No electric starter
  • 79bhp at 7000rpm crankshaft power output
  • 68bhp at the rear wheel power output
  • Top speed of 135mph (217km/h)
  • Cruises at 100 mph (161km/h) with smooth, long-legged feel
  • Rigid frame design
  • Long wheelbase
  • Taut Marzocchi suspension
  • Exemplary roadholding and braking performance
