Quick Shift System (QSS) with three settings, Up and Down
Traction Control System
Lean angle-sensitive Traction Control (TCS) incorporates 6-axis IMU
Assist & Slipper Clutch
Yes
Electrical & Electronics System
Headlight Type
LED
Taillight Type
LED
Instrumentation
Advanced, full-color TFT display
Traction Control System
Lean angle-sensitive Traction Control (TCS) incorporates 6-axis IMU
Launch Control
Four-level Lift Control System (LIF)
ABS
Yes
Chassis & Suspension
Frame Type
Slim aluminum Deltabox frame
Front Suspension
43mm Öhlins® Electronic Racing Suspension NPX fork, fully adjustable
Front Suspension Travel
120 mm / 4.7 inches
Rear Suspension
Öhlins® Electronic Racing Suspension single shock
Rear Suspension Travel
120 mm / 4.7 inches
Rake
24 °
Trail
102 mm / 4.0 inches
Rear Subframe
Magnesium subframe
Swingarm
Aluminum swingarm
Wheels & Brakes
Wheels
10-spoke cast magnesium wheels
Front Tire Size
120/70ZR17 Bridgestone® BATTLAX RACING STREET RS11F
Rear Tire Size
190/55ZR17 Bridgestone® BATTLAX RACING STREET RS11R
Front Brakes
Brembo Stylema Monobloc with Brembo Master cylinder, Dual 320mm hydraulic disc; Brake Control System and ABS
Rear Brakes
Brembo 220mm hydraulic disc; Brake Control System and ABS
ABS
Yes.
Dimension & Weights
Overall Length
2055 mm / 80.9 inches
Overall Width
690 mm / 27.2 inches
Overall Height
1165 mm / 45.9 inches
Seat Height
861 mm / 33.9 inches
Wheelbase
1405 mm / 55.3 inches
Ground Clearance
129.54 mm / 5.1 inches
Fuel Tank Capacity
17 L / 4.5 US gallons
Wet (kerb/curb) Weight
205 kg / 452 lbs
Features
Lightweight titanium connecting rods, titanium intake valves and forged pistons.
Variable Yamaha Chip Controlled Intake (YCC-I®) system adjusts length of intake based on engine speed.
Compact rocker-arm valve actuation allow for greater valve lift.
Lightweight titanium muffler and heat shield reduce weight, centralize mass.
Compact, stacked 6-speed transmission features close-ratio gearing.
Advanced assist and slipper clutch provides confident downshifts.
Advanced 998cc CP4 engine with crossplane crankshaft technology.
Four-level Lift Control System (LIF) detects front wheel lift and regulates engine power to maintain chassis attitude and forward drive.
Quick Shift System (QSS) with three settings enables clutchless upshifting and downshifting.
An integrated GPS data-logging system is enabled through Yamaha’s Communication Control Unit offering vehicle data recording with course mapping and automatic lap timing.
Three-level Launch Control System (LCS) limits engine rpm and throttle opening to maximize acceleration from a standing start.
Four-level Slide Control System (SCS) detects lateral slides and adjusts power delivery to control cornering attitude.
Lean angle-sensitive Traction Control (TCS) incorporates 6-axis IMU to adjust intervention to suit rider preference.
Four-level Power Delivery Mode (PWR) allows rider to adjust engine response to suit preference.
Three-level Engine Brake Management (EBM) system allows rider to adjust engine braking to suit preference.
Yamaha’s lean-sensitive Brake Control (BC) System works with ABS to provide progressive brake force intervention as lean increases.
High performance Bridgestone® RS11 tires offer track-worthy handling, superb traction and balanced feel.
Advanced, full-color TFT display offers selectable layouts and a wide range of vehicle information.
Full LED lighting offers a broad spread of illumination and high visibility.
Unique R1M styling features include full carbon-fiber bodywork, polished aluminum swingarm and Special Edition color scheme.
Updated seat cover texture balances both grip and ease of movement for a better sense of connection and control.
