Liquid-cooled, 2-stroke, Single cylinder, reed-valve inducted
Engine Capacity
249 cc / 15.2 cubic inches
Max Power
n/a
Max Torque
n/a
Top Speed
n/a
Fuel Tank Capacity
7 L / 1.84 US gallons
Weight (Wet/Kerb)
103 kg / 227 lbs
Seat Height
975 mm / 38.3 inches
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Yamaha YZ250 70th Anniversary Edition
Year
2025
Engine
Engine Type
Liquid-cooled, 2-stroke, Single cylinder
Displacement
249 cc / 15.2 cubic inches
Bore x Stroke
66.4 x 72 mm
Compression Ratio
8.9~10.6:1
Number of Cylinders
1
Max Horsepower
n/a
Max Torque
n/a
Engine Management System
Hitachi Astemo® Keihin PWK38S carburetor
Lubrication System
Premix
Cooling System
Liquid-cooled
Ignition System
CDI, Kick
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet multiplate clutch, hydraulic
Gearbox
Constant-mesh 5-speed
Final Drive
Chain
Electrical & Electronics System
Headlight Type
n/a
Chassis & Suspension
Frame Type
Semi double cradle
Front Suspension
KYB® Speed-Sensitive System inverted fork; fully adjustable
Front Suspension Travel
300 mm / 11.8 inches
Rear Suspension
KYB® single shock; fully adjustable
Rear Suspension Travel
315 mm / 12.4 inches
Rake
27.4 ° (Europe) 27.7 ° (US)
Trail
122 mm / 5 inches
Rear Subframe
Removable Aluminum subframe
Wheels & Brakes
Wheels
Wire aluminum wheels
Front Tire Size
80/100-21 Dunlop® Geomax MX33F
Rear Tire Size
110/90-19 Dunlop® Geomax MX33
Front Brakes
Hydraulic disc, 270mm
Rear Brakes
Hydraulic disc, 240mm
Dimension & Weights
Overall Length
2185 mm / 86 inches
Overall Width
825 mm / 32.5 inches
Overall Height
1290 mm / 50.8 inches
Seat Height
975 mm / 38.3 inches
Wheelbase
1485 mm / 58.4 inches
Ground Clearance
360 mm / 14.2 inches
Fuel Tank Capacity
7 L / 1.84 US gallons
Wet (kerb/curb) Weight
103 kg / 227 lbs
Features
Exhilarating Two-Stroke Power
Class-Leading KYB Suspension
Lightweight Frame
Rider-Friendly Chassis
High Performance Braking System
Confidence-Inspiring Ergonomics
Aggressive YZ Styling
Yamaha Power Valve System
Advanced Carburetor
Race-Developed Intake
Close-Ratio Transmission
New High-Capacity Radiator
Digital Ignition
Industry-Leading KYB Fork
Advanced KYB Shock
Aluminum Frame
Lightweight Subframe
Excel Rims
Race-Ready Tires
Race-Ready Features
Yamaha YZ250 (2025) Color Options
Icon Blue (Europe)
Team Yamaha Blue (US)
