Whether your dream destination is near or far, TRACER 9 is the most inspiring and exciting way to travel. Touring is so much more than just riding – and with its easy ergonomics, aerodynamic bodywork and generous luggage capacity, this motorcycle is designed to make sure that you and your partner can enjoy every minute of every journey.
Key Specifications Engine Type CP3 4-stroke, Liquid-cooled, DOHC, 4-valves, 3-cylinder Engine Capacity 890 cc / 54.3 cubic inches Max Power 87.5 kW / 119 PS / 117.3 hp @ 10,000 rpm Max Torque 93 Nm / 68.6 ft-lbs @ 7000 rpm Top Speed n/a Fuel Tank Capacity 18.7 L / 5 US gallons Weight (Wet/Kerb) 213 kg / 469.5 lbs Seat Height 810 – 825 mm / 32 – 32.5 inches
*n/a – information not provided by manufacturer
All Specifications Make & Model Model Yamaha Tracer 9 Year 2024
Engine Engine Type CP3 4-stroke, Liquid-cooled, DOHC, 4-valves, 3-cylinder Displacement 890cc / 54.3 cubic inches Bore x Stroke 78 x 62.1 mm Compression Ratio 11.5 : 1 Number of Cylinders 3 Max Horsepower 87.5 kW / 119 PS / 117.3 hp @ 10,000 rpm Max Torque 93 Nm / 68.6 ft-lbs @ 7000 rpm Valve Train DOHC Valves per Cylinder 4 Engine Management System Fuel injection Lubrication System Wet sump Ignition System TCI Emissions Compliance EU5
Performance Fuel Consumption 20 kmpl / 47 mpg Range ~ 370 kms / 230 miles
*n/a – information not provided by manufacturer
Transmission Clutch Multiplate wet clutch Gearbox Constant Mesh, 6-speed Final Drive Chain Quick Shifter Yes. Upshift & Downshift Traction Control System Yes Assist & Slipper Clutch Yes
Electrical & Electronics System Headlight Type LED Taillight Type LED Instrumentation Twin 3.5 inch instrument panels Connectivity Smartphone connectivity with Yamaha MyRide app Riding Modes 5 Ride modes – Sport, Street, Rain, 2 custom modes Traction Control System Yes ABS Yes Cruise Control Adaptive Cruise Control
Chassis & Suspension Frame Type Deltabox Front Suspension 41mm KYB® inverted fork, electronically adjustable with preload adjustability. With KADS (KYB® Actimatic Damper System) Front Suspension Travel 130 mm / 5.1 inches Rear Suspension KYB® single shock, electronically adjustable with remote preload adjustability Rear Suspension Travel 137 mm / 5.4 inches Rake 25 ° Trail 108 mm / 4.25 inches Swingarm Steel Swingarm
Wheels & Brakes Wheels Cast wheels Front Tire Size 120/70Z R17 M/C (58W) (Tubeless) Rear Tire Size 180/55Z R17 M/C (73W) (Tubeless) Front Brakes Hydraulic dual disc, Ø 298mm, ABS Rear Brakes Hydraulic single disc, Ø 245mm, ABS
Dimension & Weights Overall Length 2175 mm / 85.6 inches Overall Width 885 mm / 35 inches Overall Height 1430 – 1470 mm / 56.3 – 58 inches Seat Height 810 – 825 mm / 32 – 32.5 inches Wheelbase 1500 mm / 59 inches Ground Clearance 135 mm / 5.31 inches Fuel Tank Capacity 18.7 L / 5 US gallons Wet (kerb/curb) Weight 213 kg / 469.5 lbs
Features Integrated KYB Semi-Active Suspension New Adaptive Cruise Control New High Luminosity TFT Display New Radar-Linked Unified Brake System New Third Generation Quickshifter Powerful 890cc Liquid-Cooled Three-Cylinder DOHC Fuel-Injected Engine Six-Axis IMU The Revolutionary Yamaha Sport Tourer Dedicated Colorway & Premium Finish Full LED Lighting with Cornering Lights The Complete Touring Package Adjustable Riding Position Lightweight CF Aluminum Die-Cast Frame Lightweight Spin Forged Aluminum Wheels Lightweight, High-Rigidity Swingarm Nissin Radial Front Brake Master Cylinder Premium Height Adjustable Seat Strong Steel Subframe Integrated Riding Modes Lean Angle-Sensitive Traction Control System Lift Control System (LIF) MotoGP-Developed Slide Control System (SCS) Ride-by-Wire YCC-T Throttle System with APSG Advanced Intake Resonance Assist & Slipper Clutch Fracture-Split Connecting Rods Lightweight Forged Pistons Offset & Direct-Plated Cylinders Optimized Transmission Ratios Advanced Smartphone Connectivity Yamaha Tracer 9 (2024) Color Options Redline (Europe) Midnight Black (Europe) Storm Gray (US) *We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
