The R1 is an icon. Proven on the track, in the last decade alone it has won a WorldSBK championship, two Endurance World Championship titles and numerous championships at national level. Inspired by the YZR-M1 MotoGP bike, the R1 RACE reaches even higher levels of on-track performance with new aerodynamic winglets, upgraded suspension and Brembo braking system. The R1 RACE is available through the GYTR PRO Shops.
Key Specifications
Engine Type
CP4 998cc, liquid-cooled inline 4 cylinder DOHC; 4-valves per cylinder
Engine Capacity
998 cc / 61 cubic inches
Max Power
147,1 kW (200.0 PS) @ 13.500 rpm
Max Torque
113.3 Nm (11.6 kg-m) @ 11,500 rpm
Fuel Tank Capacity
17 L / 4.5 US gallons
Weight (Wet/Kerb)
201 kg / 443 lbs
Seat Height
855 mm / 33.66 inches
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Yamaha YZF-R1
Year
2024
Engine
Engine Type
CP4 998cc, liquid-cooled inline 4 cylinder DOHC; 4-valves per cylinder
Quick Shift System (QSS) with three settings, Up and Down
Traction Control System
Lean angle-sensitive Traction Control (TCS) incorporates 6-axis IMU
Assist & Slipper Clutch
Yes
Electrical & Electronics System
Headlight Type
LED
Taillight Type
LED
Instrumentation
Advanced, full-color TFT display
Riding Modes
Power Selection Modes (PWR)
Traction Control System
Lean angle-sensitive Traction Control (TCS) incorporates 6-axis IMU
Launch Control
Lift Control System (LIF)
ABS
Yes
Chassis & Suspension
Frame Type
Slim aluminum Deltabox frame
Front Suspension
43mm KYB® inverted fork, fully adjustable
Front Suspension Travel
120 mm / 4.7 inches
Rear Suspension
KYB® single shock, Linkage-Type, fully adjustable
Rear Suspension Travel
120 mm / 4.7 inches
Rake
24 °
Trail
102 mm / 4.0 inches
Rear Subframe
Magnesium subframe
Swingarm
Aluminum swingarm
Wheels & Brakes
Wheels
10-spoke cast magnesium wheels
Front Tire Size
120/70 ZR17M/C (58W) Tubeless
Rear Tire Size
190/55 ZR17M/C (75W) Tubeless
Front Brakes
Brembo Stylema Monobloc with Brembo Master cylinder, Dual 320mm hydraulic disc; Brake Control System and ABS
Rear Brakes
Brembo 220mm hydraulic disc; Brake Control System and ABS
ABS
Yes.
Dimension & Weights
Overall Length
2055 mm / 80.9 inches
Overall Width
690 mm / 27.2 inches
Overall Height
1165 mm / 45.9 inches
Seat Height
855 mm / 33.7 inches
Wheelbase
1405 mm / 55.3 inches
Ground Clearance
130 mm / 5.1 inches
Fuel Tank Capacity
17 L / 4.5 US gallons
Wet (kerb/curb) Weight
201 kg / 443 lbs
Features
Cabon Fibre Moto-GP inspired downforce winglets
Six axis IMU
Traction Control (TCS)
Slide Control (SCS)
Brake Control (BC)
Lift Control (LIF)
Launch Control (LCS)
3 Mode Engine Brake Management (EBM)
QuickShift System (QSS)
Power Selection Modes (PWR)
Yamaha Chip Controlled Throttle (YCC-T)
Yamaha YZF-R1 Race (2025 – ) Color Options
Tech Black
