Pure adventure, absolute advantage. The most all-road capable large capacity adventure motorcycle you can buy, the Rally Pro will take your adventure to the next level.
Key Specifications
| Engine Type | Liquid-cooled, 12 valve, DOHC, inline 3-cylinder |
| Engine Capacity | 1160 cc |
| Max Power | 147 HP / 150PS (110.4kW) @ 9,000rpm |
| Max Torque | 130 NM – 95 Lb/Ft @ 7,000 rpm |
| Top Speed | ~ 220 kmph / 137 mph |
| Fuel Tank Capacity | 20 L / 5.28 US gallons |
| Weight (Wet/Kerb) | 250 kg / 549 lbs |
| Seat Height | 873.76 mm / 34.4 inches (low position) 894.8 mm / 35.23 inches (high position) |
*n/a – information not provided by manufacturer
All Specifications
Make & Model
| Model | Triumph Tiger 1200 Rally PRO |
| Year | 2024 – |
Engine
| Engine Type | Liquid-cooled, 12 valve, DOHC, inline 3-cylinder |
| Displacement | 1160 cc |
| Bore x Stroke | 90 mm x 60.4 mm |
| Compression Ratio | 13.2 : 1 |
| Number of Cylinders | 3 |
| Max Horsepower | 147 HP / 150PS (110.4kW) @ 9,000rpm |
| Max Torque | 130 NM – 95 Lb/Ft @ 7,000 rpm |
| Valve Train | DOHC |
| Valves per Cylinder | 4 |
| Engine Management System | Multipoint sequential electronic fuel injection with electronic throttle control |
| Lubrication System | Pressure Lubrication (wet sump) |
| Ignition System | Fully electronic ignition |
| Fuel | Unleaded, 95 RON (U.S. 89 CLC/AKI) |
| Exhaust System | Stainless steel 3 into 1 header system, side mounted stainless steel silencer |
Performance
| Top Speed | ~ 220 kmph / 137 mph |
*n/a – information not provided by manufacturer
Transmission
| Clutch | Wet, multi-plate, slip and assist |
| Gearbox | 6-speed gearbox, Constant Mesh |
| Primary Drive Ratio | 53:84 |
| Gear Ratios | 1st gear – 16:42 2nd gear – 22:43 3rd gear – 22:36 4th gear – 24:34 5th gear – 26:31 6th gear – 31:32 |
| Final Drive | Shaft drive |
| Quick Shifter | Yes |
| Traction Control System | Yes |
| Assist & Slipper Clutch | Yes |
Electrical & Electronics System
| Battery | HJTZ14S-FPZ |
| Alternator/Generator | 12 Volt, 8 Ah |
| Headlight Type | LED |
| Taillight Type | LED |
| Instrumentation | Full-colour 7” TFT instrument pack with My Triumph Connectivity System |
| Riding Modes | 6 riding modes (Road, Rain, Sport, Rider Configurable, Off-Road and Off-Road Pro) |
| Traction Control System | Yes |
| ABS | ABS Cornering system |
| Cruise Control | Yes |
Chassis & Suspension
| Frame Type | Tubular steel frame, with forged aluminium outriggers |
| Front Suspension | Showa 49mm, semi-active damping USD forks |
| Front Suspension Travel | 220 mm / 8.66 inches |
| Rear Suspension | Showa semi-active damping monoshock, with automatic electronic preload adjustment and New Active Preload Reduction feature. Depending on the combined weight of rider, pillion and luggage, this feature could lower the riding height by up to 0.78in when the motorcycle comes to a standstill, offering greater ease and confidence |
| Rear Suspension Travel | 220 mm / 8.66 inches |
| Rake | 23.7 ° |
| Trail | 111.76 mm / 4.4 inches |
| Rear Subframe | Fabricated, bolt-on aluminium rear subframe |
| Swingarm | Twin-sided, cast aluminium alloy |
Wheels & Brakes
| Wheels | Spoked (Tubeless) |
| Front Wheel/Rim Size | 2.15 x 21″ |
| Front Tire Size | 90/90-21 (M/C 54V TL), Metzeler Karoo Street |
| Rear Wheel/Rim Size | 4.25 x 18″ |
| Rear Tire Size | 150/70R18 (M/C 70V TL), Metzeler Karoo Street |
| Front Brakes | Brembo M4.30 Stylema monoblock radial calipers, OC-ABS, twin 320mm floating discs. Magura HC1 span adjustable radial master cylinder with separate reservoir |
| Rear Brakes | Brembo single piston caliper, OC-ABS, single 282mm disc. Rear master cylinder with remote reservoir. |
| ABS | ABS with Cornering ABS |
Dimension & Weights
| Overall Width | 848.8 mm / 33.42 inches |
| Overall Height | Low screen position – 1487 mm / 58.54 inches High screen position – 1547 mm / 60.9 inches |
| Seat Height | 873.76 mm / 34.4 inches (low position) 894.8 mm / 35.23 inches (high position) |
| Wheelbase | 1560 mm / 61.41 inches |
| Ground Clearance | 220 mm / 8.6 inches |
| Fuel Tank Capacity | 20 L / 5.28 US gallons |
| Wet (kerb/curb) Weight | 250 kg / 549 lbs |
Riding Aids
- Riding Modes
- Cornering ABS
- Traction Control
- Quick Shift
Features
- Cruise Control
- Shift Assist
- Hill Hold
- Riding Modes
- Tyre Pressure Monitoring System
- Adaptive Cornering Lighting
- All-LED Lighting
- LED Auxiliary Lights
- 7 inch TFT instruments with My Triumph Connectivity System
- ABS and Traction Control
- Heated Grips
- Heated Rider and Passenger Seats
Triumph Tiger 1200 Rally PRO (2024 – ) Color Options
- Jet Black
- Matte Khaki Green
- Matte Sandstorm
