With the new generation’s major step up in technology and stunning looks, the RS adds the highest specification brakes, the most advanced handling setup and sets a new benchmark as THE most powerful Street Triple ever.
Key Specifications
Engine Type
Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity
765 cc
Max Power
130 PS / 128 HP (95.6 kW) @ 12,000 rpm
Max Torque
80 Nm / 59 ft lb @ 9,500 rpm
Top Speed
~ 220 kmph / 136.7 mph
Fuel Tank Capacity
15 L / 3.96 US gallons
Weight (Wet/Kerb)
188 kg / 414 lbs
Seat Height
Standard – 836 mm / 32.91 inches Accessory low seat and suspension adaption – 798 mm / 31/42 inches
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Triumph Street Triple 765 RS
Year
2021 –
Engine
Engine Type
Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Displacement
765 cc
Bore x Stroke
78 mm x 53.4 mm
Compression Ratio
13.25 : 1
Number of Cylinders
3
Max Horsepower
130 PS / 128 HP (95.6 kW) @ 12,000 rpm
Max Torque
80 Nm / 59 ft lb @ 9,500 rpm
Valve Train
DOHC
Valves per Cylinder
4
Engine Management System
Multipoint sequential electronic fuel injection with electronic throttle control
Lubrication System
Pressure lubrication, wet sump
Ignition System
Fully electronic ignition
Exhaust System
Stainless steel 3 into 1 header system with low single sided stainless steel silencer
Emissions Compliance
Euro 5
Performance
Top Speed
~ 220 kmph / 136.7 mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet mulit-plate, slip assist
Gearbox
6 speed, constant mesh
Final Drive
Chain X-ring
Quick Shifter
Triumph Shift Assist Up-and-Down Quickshifter
Traction Control System
Switchable Optimized Traction Control
Assist & Slipper Clutch
Optimized Cornering ABS
Electrical & Electronics System
Headlight Type
LED
Taillight Type
LED
Instrumentation
Full colour 5″ TFT instruments
Riding Modes
5 Modes – Rain, Road, Sport, Track, Rider
Traction Control System
Switchable Optimized Traction Control
Launch Control
Front Wheel Lift Control
ABS
Optimized Cornering ABS
Chassis & Suspension
Frame Type
Aluminum beam twin spar frame
Front Suspension
Showa 41 mm upside down Big Piston Forks (BPF), adjustable compression and rebound damping, and preload adjustment
Front Suspension Travel
115 mm / 4.52 inches
Rear Suspension
Öhlins STX40 piggyback reservoir monoshock, adjustable compression and rebound damping, and preload adjustment
Single 220 mm disc, Brembo single piston caliper, OC-ABS
ABS
Optimized Cornering ABS
Dimension & Weights
Overall Width
792 mm / 31.18 inches
Overall Height
1064 mm / 41.89 inches
Seat Height
Standard – 836 mm / 32.91 inches Accessory low seat and suspension adaption – 798 mm / 31/42 inches
Wheelbase
1399 mm / 55.08 inches
Fuel Tank Capacity
15 L / 3.96 US gallons
Wet (kerb/curb) Weight
188 kg / 414 lbs
Triumph Street Triple 765 RS (2021 – ) Color Options
Phantom Black
Granite
Carnival Red
Cosmic Yellow
