Triumph Scrambler 400 X (2024 - )

With its agile handling, class-leading performance, and premium finish, the Scrambler 400 X is cool and capable.

Key Specifications

Engine Type	Liquid-cooled, 4 valve, DOHC, single-cylinder
Engine Capacity	398 cc
Max Power	39.5 HP (40PS) @ 8,000 RPM
Max Torque	37.55 Nm / 27.7 ft lb @ 6,500 rpm
Top Speed	~ 150 kmph / 93.2 mph
Fuel Tank Capacity	13 L / 3.43 US gallons
Weight (Wet/Kerb)	179 kg / 395 lbs
Seat Height	835 mm / 32.87 inches

*n/a – information not provided by manufacturer

2024-triumph-scrambler-400-x-throttlecraze.com-4_throttlecraze.com

All Specifications

Make & Model

Model	Triumph Scrambler 400 X
Year	2024 –

Engine

Engine Type	Liquid-cooled, 4 valve, DOHC, single-cylinder
Displacement	398 cc
Bore x Stroke	89 mm x 64 mm
Compression Ratio	12 : 1
Number of Cylinders	1
Max Horsepower	39.5 HP (40PS) @ 8,000 RPM
Max Torque	37.55 Nm / 27.7 ft lb @ 6,500 rpm
Valve Train	SOHC
Valves per Cylinder	4
Engine Management System	Bosch electronic fuel injection with electronic throttle control
Lubrication System	Wet sump and forced lubrication with pump driven oil delivery
Ignition System	Fully electronic ignition
Fuel	Unleaded, 91 RON (U.S. 87 CLC/AKI)
Exhaust System	Stainless twin-skin header system with stainless steel silencer
Emissions Compliance	Euro 5

Performance

Top Speed

~ 150 kmph / 93.2 mph

*n/a – information not provided by manufacturer

Transmission

Clutch	Wet, multi-plate, slip & assist
Gearbox	6-speed gearbox with torque-assist clutch
Primary Drive Ratio	88:31
Gear Ratios	1st gear – 34:12 2nd gear – 29:15 3rd gear – 27:19 4th gear – 24:21 5th gear – 22:23 6th gear – 21:25
Final Drive	520 Series X-ring chain
Traction Control System	Switchable Traction Control

Electrical & Electronics System

Battery	ETZ-9 or YTX9-BS
Alternator/Generator	14 Volt, 18.5 Amp at 4,000 rpm
Headlight Type	LED
Taillight Type	LED
Instrumentation	Analogue speedometer with integrated multi-function LCD screen
Traction Control System	Switchable Traction Control
ABS	Dual-channel ABS (switchable on Scrambler 400 X for off-road use)

Chassis & Suspension

Frame Type	Hybrid spine/perimeter, tubular steel
Front Suspension	43mm upside down Big Piston forks
Front Suspension Travel	150 mm / 6 inches
Rear Suspension	Gas monoshock RSU with external reservoir and pre-load adjustment
Rear Suspension Travel	150 mm / 6 inches
Rake	23.2 °
Trail	108 mm / 4.25 inches
Rear Subframe	Bolt-on rear subframe
Swingarm	Twin-sided, cast alloy aluminum

Wheels & Brakes

Wheels	Cast aluminum alloy 10 spoke
Front Wheel/Rim Size	2.5 x 19″
Front Tire Size	100/90-19
Rear Wheel/Rim Size	3.5 x 17″
Rear Tire Size	140/80-17
Front Brakes	320mm fixed disc, four-piston radial caliper, ABS
Rear Brakes	230mm fixed disc, ByBreTM single piston floating caliper, ABS
ABS	Dual-channel ABS (switchable on Scrambler 400 X for off-road use)

Dimension & Weights

Overall Length	2117 mm / 83.34 inches
Overall Width	901 mm / 35.47 inches
Overall Height	1169 mm / 46.02 inches
Seat Height	835 mm / 32.87 inches
Wheelbase	1418 mm / 55.83 inches
Fuel Tank Capacity	13 L / 3.43 US gallons
Wet (kerb/curb) Weight	179 kg / 395 lbs

Triumph Scrambler 400 X (2024 – ) Color Options

Matte Khaki Green / Fusion White
Phantom Black / Silver Ice
Aluminum / Baja Orange

2024-triumph-scrambler-400-x-throttlecraze.com-3_throttlecraze.com

2024-triumph-scrambler-400-x-throttlecraze.com-2_throttlecraze.com

2024-triumph-scrambler-400-x-throttlecraze.com-1_throttlecraze.com
