KTM 250 XC (2025)

ktm-2025-250-XC-throttlecraze.com-4_throttlecraze.com

At the sharp end of the cross-country performance stakes, you’ll find the 2025 KTM 250 XC. Not only does it boast one of the most potent powerplants around, it now gets upgraded suspension, a reworked chassis, and a new airbox for improved airflow. In simple terms, the 2025 KTM 250 XC is ready to extend its legendary status in the cross-country pits.

Key Specifications

Engine Type	1-cylinder, 2-stroke engine
Engine Capacity	249 cc
Max Power	n/a
Max Torque	n/a
Top Speed	n/a
Fuel Tank Capacity	9 L / 2.37 US gallons
Weight (Wet/Kerb)	~ 112.35 kg / 247.68 lbs
Seat Height	954 mm / 37.55 inches

*n/a – information not provided by manufacturer

ktm-2025-250-XC-throttlecraze.com-1_throttlecraze.com

All Specifications

Make & Model

Model	KTM 250 XC
Year	2025

Engine

Engine Type	1-cylinder, 2-stroke engine
Displacement	249 cc
Bore x Stroke	66.4 x 72 mm
Number of Cylinders	1
Max Horsepower	n/a
Max Torque	n/a
Engine Management System	Vitesco Technologies EMS
Fuel-mixture System	Keihin EFI, throttle body 39 mm
Ignition System	Electronic ignition
Fuel	Super Unleaded (ROZ 95)

Performance

Top Speed	n/a
Acceleration (0-100 km/h, 0-60 mph)	n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Wet, DS multi-disc clutch, Brembo hydraulics
Gearbox	6 speed transmission, claw shift
Primary Drive Ratio	26:72
Gear Ratios	1st gear -17:35 2nd gear – 17:28 3rd gear – 18:25 4th gear – 22:26 5th gear – 23:23 6th gear – 26:22
Final Drive	Chain (520 X-Ring)

Electrical & Electronics System

Battery	12 V, HJTZ5S-FP-C, Lithium Ion
Starter	Electric starter
Headlight Type	LED
Taillight Type	LED
Riding Modes	2 Maps (Map 1 & 2)
Traction Control System	Yes
Launch Control	Yes

Chassis & Suspension

Frame Type	Central double-cradle-type 25CrMo4 steel
Front Suspension	WP XACT cartridge Ø 48 mm
Front Suspension Travel	300 mm / 11.8 inches
Rear Suspension	WP XACT Monoshock with linkage
Rear Suspension Travel	300 mm / 11.8 inches
Rear Subframe	Aluminum-reinforced polyamide

Wheels & Brakes

Wheels	Wired Spoke RIms
Front Tire Size	80/100 -21 51M TT
Rear Tire Size	110/100 – 18 64 M S TT
Front Brakes	Disc brake 260 mm
Rear Brakes	Disc brake 220 mm

Dimension & Weights

Seat Height	954 mm / 37.55 inches
Wheelbase	1493 mm / 58.77 inches
Ground Clearance	343 mm / 13.5 inches
Fuel Tank Capacity	9 L / 2.37 US gallons
Wet (kerb/curb) Weight	~ 112.35 kg / 247.68 lbs
Dry Weight	~ 102.1 kg / 225.09 lbs
Max Load Capacity	335 kg / 738.5 lbs

ktm-2025-250-XC-throttlecraze.com-2_throttlecraze.com
