The newest member of the W family nods to the past but rides full throttle into the future. With design inspired by the 1965 650-W1 model, the W230 motorcycle packs a modern punch with Kawasaki’s proven 233cc fuel-injected 4-stroke engine. The original icon continues with a light weight, low seat height, and friendly power character that opens ‘60s design to more riders than ever before.
Modern LCD display with round, vintage-style gauges
ABS
Yes
Chassis & Suspension
Frame Type
Semi-double cradle, steel
Front Suspension
37 mm telescopic fork
Front Suspension Travel
117 mm / 4.6 inches
Rear Suspension
Twin shocks with spring preload adjustability
Rear Suspension Travel
94 mm / 3.7 inches
Rake
27.0 °
Trail
94 mm / 3.7 inches
Wheels & Brakes
Wheels
Spoked wheels
Front Tire Size
90/90-18
Rear Tire Size
110/90-17
Front Brakes
Single 265mm disc with 2-piston calipers, ABS
Rear Brakes
Single 220mm disc with 1-piston caliper, ABS
Dimension & Weights
Overall Length
2124 mm / 83.6 inches
Overall Width
798 mm / 31.4 inches
Overall Height
1090 mm / 42.9 inches
Seat Height
745 mm / 29.3 inches
Wheelbase
1415 mm / 55.7 inches
Ground Clearance
150 mm / 5.9 inches
Fuel Tank Capacity
12 L / 3.1 US gallons
Wet (kerb/curb) Weight
315.2 lbs / 143 kgs
Features
Retro Classic Styling
ABS
Kawasaki W230 ABS (2026) Color Options
Metallic Ocean Blue/Ebony
