The 903cc V-twin powered Kawasaki Vulcan® 900 lineup of classic cruisers has all the style and attitude of a one-of-a-kind build. From the detailed paint job to the intense exhaust, the Vulcan 900 is an artful expression of individuality. Enjoy the dynamic fusion of hand-built design and premium fit and finish of the Vulcan 900—a tantalizing combination that could only come from Kawasaki.
Key Specifications
Engine Type
4-stroke, 55-degree V-twin, liquid-cooled
Engine Capacity
903 cc / 55 cubic inches
Max Power
n/a
Max Torque
58.2 lb-ft / 79 nm @ 3,500 rpm
Top Speed
n/a
Fuel Tank Capacity
20 L / 5.3 US gallons
Weight (Wet/Kerb)
610.8 lbs / 277 kg
Seat Height
686 mm / 27 inches
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Kawasaki Vulcan 900 Custom
Year
2025
Engine
Engine Type
4-stroke, 55-degree V-twin, liquid-cooled
Displacement
903 cc / 55 cubic inches
Bore x Stroke
88 x 74.2 mm
Compression Ratio
9.5 : 1
Number of Cylinders
2
Max Horsepower
n/a
Max Torque
58.2 lb-ft / 79 nm @ 3,500 rpm
Valve Train
DOHC
Valves per Cylinder
4
Engine Management System
DFI® with 34mm throttle bodies (2), with sub-throttle valves
Lubrication System
Forced lubrication, semi‑dry sump
Cooling System
Liquid Cooled
Ignition System
TCBI with Electronic Advance
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multi disc
Gearbox
5-speed with positive neutral finder
Final Drive
Kevlar-reinforced belt
Electrical & Electronics System
Headlight Type
LED
Taillight Type
LED
Chassis & Suspension
Frame Type
Semi-double cradle, high-tensile steel
Front Suspension
41mm Showa telescopic fork
Front Suspension Travel
150 mm / 5.9 inches
Rear Suspension
Uni-Trak® swingarm, 7-way adjustable spring preload
Rear Suspension Travel
105 mm / 4.1 inches
Rake
33 °
Trail
183 mm / 7.2 inches
Wheels & Brakes
Wheels
Cast alloy wheels
Front Tire Size
80/90-21
Rear Tire Size
180/70-15
Front Brakes
Single 300mm hydraulic disc
Rear Brakes
Single 270mm hydraulic disc
Dimension & Weights
Overall Length
2406 mm / 94.7 inches
Overall Width
894 mm / 35.2 inches
Overall Height
1120 mm / 44.1 inches
Seat Height
686 mm / 27 inches
Wheelbase
1646 mm / 64.8 inches
Ground Clearance
140 mm / 5.5 inches
Fuel Tank Capacity
20 L / 5.3 US gallons
Wet (kerb/curb) Weight
610.8 lbs / 277 kg
Features
Dual Throttle Valves
Wide drag bars and forward-mounted footpegs
Low center of gravity for easy handling
Custom styling with teardrop tank
Parallel slash-cut pipes
Pinstripe wheels
Kawasaki Vulcan 900 Custom (2025) Color Options
Candy Fire Red/Ebony
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
